DAIPU 4K 1080P HD 3 10 12 20 30X conference camera ptz Optic USB NDI SDI system Auto Tracking Video Conference

DAIPU 4K 1080P HD 3 10 12 20 30X conference camera ptz Optic USB NDI SDI system Auto Tracking Video Conference

Цена:126,00 $ - 146,00 $*

Количество:

→→Click here to inquiry←Get discount price.
WhatsApp/WeChat: +8615638872728

Product Description

	UK100	UK203	UK310	UK510	UK512	UK520
ZOOM	prime lens	3X ZOOM	10X ZOOM	10X ZOOM	12X ZOOM	20X ZOOM
wide angle	105°	95°	55°	52°	62°	58.7°
interface	USB2.0、 RS232、 RS485	USB2.0、RS232、 RS485	RS232、RS485、USB2.0	CVBS、HDMI、RS232、USB3.0、 LAN	CVBS、HDMI、RS232、USB3.0、 LAN	CVBS、HDMI、RS232、USB3.0、 LAN

Specification

Parameters of camera and lens
Product Name	PTZ Camera Video Conference
Image sensor	1/2.8-inch high quality HD CMOS sensor
Effective pixels	16:9 2.1 million effective pixels
Video format	1080p30, 720p30, 800600p30, 640480p30, 320*240p30
Angle of view	1x, 105º
Minimum illumination	0.1Lux
White balance	Automatic
Focus	1x, Manual
Signal to noise ratio	>52dB

Input/output interface
HD video	USB2.0
Interface of control signal	8-core mini DIN(RS232), 3.81 seat (RS485)
Format of control signal	Starting position: position 1, data position: position 8, stop position, position 1, Baud rate: 9600/4800s
Power interface	HEC3800 power socket
Operating system supported	Windows 7, Windows 10,Linux
USB protocol	UVC1.1

Routine parameters
Mechanical performance	Horizontal rotation±175 degrees; pitch rotation: -30 degrees~+90 degrees
		Horizontal control speed: 1-100°/ second; Pitch control speed: 1-60°/second.
		Speed level at preset position: 100°/seconds, pitch 60°/second
		Accuracy of preset position is 0.5 degree
		There are 255 preset positions where the user can set the preset status
Power adapter	AC110V-AC220V rotating DC12V/2A
Input voltage	DC12V(DC11.5-DC12.5V)
Power consumption	10W(Max)
Storage temperature	-10℃ to +60℃
Working temperature	0℃ to +45℃
Use environment	Indoor
