Высокопроизводительный шариковый подшипник с глубоким желобом ЯПОНИЯ NSK
- Категория: Deep Groove Ball Bearings >>>
- Поставщик: Shandong,Huafei,Bearing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.33 $* | 0.91 $* |
| Aug-19-2025 | 0.28 $* | 0.89 $* |
| Jul-19-2025 | 0.27 $* | 0.87 $* |
| Jun-19-2025 | 0.26 $* | 0.39 $* |
| May-19-2025 | 0.97 $* | 0.14 $* |
| Apr-19-2025 | 0.22 $* | 0.53 $* |
| Mar-19-2025 | 0.95 $* | 0.50 $* |
| Feb-19-2025 | 0.25 $* | 0.46 $* |
| Jan-19-2025 | 0.76 $* | 0.95 $* |
Характеристики
Product Description
Product introduction:
Deep groove ball bearings (GB/T 276-2003), formerly known as single-row centripetal ball bearings, are the most widely used rolling bearings. It is characterized by small friction resistance, high speed, can be used to bear radial load or radial and axial combined load at the same time on the machinery, can also be used to bear axial load on the machinery, such as small power motors, automobile and tractor gearboxes, machine tool gearboxes, general machinery, tools and so on.
The basic parameters:
Deep groove ball bearing is the most common type of rolling bearing.
The basic type of deep groove ball bearing consists of an outer ring, an inner ring, a group of steel balls and a group of cages. There are two types of deep groove ball bearings: single row and double row. Deep groove ball structure is also divided into sealed and open structure. Open type means that the bearing does not have a sealed structure. The dustproof seal cover is made of steel sheet stamping, which only plays a simple role in preventing dust from entering the bearing raceway. Oil-proof type is contact oil seal, which can effectively prevent grease spillover in the bearing.
Single row deep groove ball bearing type code is 6, double row deep groove ball bearing code is 4. Its structure is simple, easy to use, is the production of the most common, the most widely used kind of bearings.
Use the application:
Deep groove ball bearings can be used in gearboxes, instruments and meters, motors, household appliances, internal combustion engines, traffic vehicles, agricultural machinery, construction machinery, engineering machinery, roller type roller skates, yo-yo, etc.
Deep groove ball bearings (GB/T 276-2003), formerly known as single-row centripetal ball bearings, are the most widely used rolling bearings. It is characterized by small friction resistance, high speed, can be used to bear radial load or radial and axial combined load at the same time on the machinery, can also be used to bear axial load on the machinery, such as small power motors, automobile and tractor gearboxes, machine tool gearboxes, general machinery, tools and so on.
The basic parameters:
Deep groove ball bearing is the most common type of rolling bearing.
The basic type of deep groove ball bearing consists of an outer ring, an inner ring, a group of steel balls and a group of cages. There are two types of deep groove ball bearings: single row and double row. Deep groove ball structure is also divided into sealed and open structure. Open type means that the bearing does not have a sealed structure. The dustproof seal cover is made of steel sheet stamping, which only plays a simple role in preventing dust from entering the bearing raceway. Oil-proof type is contact oil seal, which can effectively prevent grease spillover in the bearing.
Single row deep groove ball bearing type code is 6, double row deep groove ball bearing code is 4. Its structure is simple, easy to use, is the production of the most common, the most widely used kind of bearings.
Use the application:
Deep groove ball bearings can be used in gearboxes, instruments and meters, motors, household appliances, internal combustion engines, traffic vehicles, agricultural machinery, construction machinery, engineering machinery, roller type roller skates, yo-yo, etc.
Deep Groove Ball Bearing Model
Principal dimensions | Basic load ratings | Fatigue load limit | Speed ratings | Designations | ||||||||||
dynamic | static | Reference speed | Limiting speed | Bearing | Snap ring | |||||||||
40 | 90 | 23 | 42.3 | 24 | 1.02 | 17000 | 8500 | 6308-2RZ | ||||||
40 | 90 | 23 | 42.3 | 24 | 1.02 | 17000 | 8500 | 6308-2Z | ||||||
40 | 90 | 23 | 42.3 | 24 | 1.02 | 17000 | 11000 | 6308 | ||||||
40 | 90 | 23 | 42.3 | 24 | 1.02 | 17000 | 11000 | 6308 N | ||||||
40 | 90 | 23 | 42.3 | 24 | 1.02 | 17000 | 11000 | 6308 NR | SP 90 | |||||
40 | 90 | 23 | 42.3 | 24 | 1.02 | 17000 | 11000 | 6308-Z | ||||||
40 | 90 | 23 | 42.3 | 24 | 1.02 | 17000 | 11000 | 6308-ZNR | SP 90 | |||||
40 | 90 | 23 | 42.3 | 24 | 1.02 | 5000 | 6308-2RS1 | |||||||
40 | 90 | 23 | 42.3 | 24 | 1.02 | 5000 | 6308-2RSH | |||||||
40 | 90 | 23 | 42.3 | 24 | 1.02 | 5000 | 6308-RS1 | |||||||
Specification
Applicable Industries | Internal combustion engine, Transportation vehicles, Agricultural machinery, Construction machinery |
Bore Size | 35mm - 40mm |
Model Number | NSK 6308 |
Precision Rating | p0,p2,p4,p6 |
Seals Type | rubber seal,metal seal,open without seal |
Number of Row | Single Row |
Place of Origin | Japan |
Product name | Deep Grove Ball Bearing |
Material | Steel |
Application | Internal combustion engine |
Feature | Long Life |
Size | 40*90*23mm |
Cage | Steel Cage |
Service | OEM Customized Services |
Package | Original Package |
Brand | NSK |
Model | NSK 6308 |
More Products
Company Profile
Shandonghuafeibearing co.,LTD. With industry and trade as one, specialized in bearing design,research and development, production, sales. Own import and export righet, and passed GB/ T19001-2016/ISO9001:2015 qualit management system
certification.Specializing in the production of automotive hub bearings tapered roller bearings, deep groove ball bearings,spherical bearings and various non-standard bearings,can be customized according to customer drawings, samples,OEM processing production services.OEM processing production services. The company has advanced production equipment, with strong technical force,high-quality staff team, optimize product design, improve processing technology, strictly in accordance with international standards to control the quality of products,so that our products have reached the domestic advanced level, at the same time, our brand "SHJZ" has been designated as adesignated supplier by many foreign customers. The company adheres to the business philosophy of "customer-oriented, honest managnment continuousimprovement", and adopts the enterprise standard higher than the national standard for production.
certification.Specializing in the production of automotive hub bearings tapered roller bearings, deep groove ball bearings,spherical bearings and various non-standard bearings,can be customized according to customer drawings, samples,OEM processing production services.OEM processing production services. The company has advanced production equipment, with strong technical force,high-quality staff team, optimize product design, improve processing technology, strictly in accordance with international standards to control the quality of products,so that our products have reached the domestic advanced level, at the same time, our brand "SHJZ" has been designated as adesignated supplier by many foreign customers. The company adheres to the business philosophy of "customer-oriented, honest managnment continuousimprovement", and adopts the enterprise standard higher than the national standard for production.
Packing & Delivery
Payment terms
A.T/TB.D/P
C.D/A
D.Paypal
E.Western union
Package
A.tube package + outer carton + pallets
B.single box + outer carton + pallets
C.tube package + middle box + outer carton + pallets
D.According to your request.
A.T/TB.D/P
C.D/A
D.Paypal
E.Western union
Package
A.tube package + outer carton + pallets
B.single box + outer carton + pallets
C.tube package + middle box + outer carton + pallets
D.According to your request.
FAQ
1.Are you trading company other manufacturer ?
We are factory.
2.How long is your delivery time?
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3.Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge.
4.You provide free consultation service?
Yes, before, during and after order, anytime.
5.Why should I choose your products?
Our products are high quality and low price.
