Бульдозер Shantui бульдозер 160hp гусеничный SD16 лучшее
- Категория: Bulldozers >>>
- Поставщик: Shandong,Hero,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 94486.93 $* | 99210.93 $* |
| Aug-19-2025 | 93692.17 $* | 98377.30 $* |
| Jul-19-2025 | 78606.39 $* | 82536.59 $* |
| Jun-19-2025 | 92104.97 $* | 96709.64 $* |
| May-19-2025 | 80194.51 $* | 84204.9 $* |
| Apr-19-2025 | 90516.59 $* | 95042.68 $* |
| Mar-19-2025 | 89722.0 $* | 94208.70 $* |
| Feb-19-2025 | 88928.59 $* | 93374.74 $* |
| Jan-19-2025 | 88134.40 $* | 92541.67 $* |
Характеристики
Product Show
Product Paramenters
Parameter name | SD16 (Standard version) | SD16C (Coal version) | SD16E (Extended version) | SD16L (Super-wetland version） | SD16R (Environmental sanitation version) | SD16D (Desert version) |
Operating weight (Kg) | 17000 | 17500 | 17346 | 18400 | 18400 | 18200 |
Ground pressure (kPa) | 58 | 50 | 55 | 25 | 25 | 33.2 |
Engine model | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) |
Rated power/rated speed (kW/rpm) | 131/1850 | 131/1850 | 131/1850 | 131/1850 | 131/1850 | 131/1850 |
Overall dimensions of machine (mm) | 5140*3388*3032 | 5427*3900*3032 | 5345*3388*3032 | 5262*4150*3074 | 5262*4150*3074 | 5262*4150*3074 |
Forward speed (km/h) | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 |
Reversing speed (km/h) | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 |
Center distance of track (mm) | 1880 | 1880 | 1880 | 2300 | 2300 | 2300 |
Width of track shoes (mm) | 510/560/610 | 610 | 560/510/610 | 1100/950 | 1100/660 | 810 |
Ground length（mm） | 2430 | 2430 | 2635 | 2935 | 2935 | 2935 |
Fuel tank (L) | 315 | 315 | 315 | 315 | 315 | 315 |
Blade type | Angle Blade, Straight tilting blade and U-shaped Blade | Coal blade | Angle Blade, Straight tilting blade and U-shaped Blade | Straight tilting blade | Sanitation blade | Straight tilting blade |
Digging depth (mm) | 540 | 540 | 540 | 485 | 485 | 485 |
Ripper type | Three-tooth ripper | —— | Three-tooth ripper | —— | —— | —— |
Ripping depth (mm) | 570 | —— | 570 | —— | —— | —— |
Recommend Products
HOT OF SHANTUI
Products Description
Power System
● The installed WP10 electronically controlled engine conforms to the China-III non-road machinery emission regulation, featuring strong power, high efficiency and energy-saving, and low maintenance cost.
● The rated power reaches 131kW, featuring high torque reserve coefficient.
● The radially sealed intake system is applied to effectively prolong the engine life.
● The installed WP10 electronically controlled engine conforms to the China-III non-road machinery emission regulation, featuring strong power, high efficiency and energy-saving, and low maintenance cost.
● The rated power reaches 131kW, featuring high torque reserve coefficient.
● The radially sealed intake system is applied to effectively prolong the engine life.
Drive system
● The curves of drive system and engine are perfectly matched to achieve more extensive high-efficiency zone and higher
transmission efficiency.
● Shantui’s self-made drive system features stable performance and reliable quality and has been long proved by the market.
● The curves of drive system and engine are perfectly matched to achieve more extensive high-efficiency zone and higher
transmission efficiency.
● Shantui’s self-made drive system features stable performance and reliable quality and has been long proved by the market.
Driving/Riding Environment
● The hexahedral cab provides super-large interior space and broad vision and the ROPS/FOPS can be installed depending on specific needs to ensure high safety and reliability.
● The electronic control hand and foot accelerators guarantee more accurate and comfortable operations.
● The intelligent display and control terminal and the A/C and heating system are installed to provide more abundant personalized driving/riding experience and enable you to understand system status at any time, featuring high intelligence and convenience.
● The hexahedral cab provides super-large interior space and broad vision and the ROPS/FOPS can be installed depending on specific needs to ensure high safety and reliability.
● The electronic control hand and foot accelerators guarantee more accurate and comfortable operations.
● The intelligent display and control terminal and the A/C and heating system are installed to provide more abundant personalized driving/riding experience and enable you to understand system status at any time, featuring high intelligence and convenience.
Working adaptability
● Shantui’s stable and reliable chassis system is applicable to diversified severe working conditions.
● The product features long ground length, high ground clearance, stable driving, and good trafficability.
● The straight tilting blade, U-blade, angle blade, coal blade, rock blade, environmental sanitation blade, ripper, and
traction frame can be installed depending on specific working condition to achieve higher working adaptability. The optional LED working lamps improve the illumination capability during nighttime operations to achieve higher safety and reliability.
● Shantui’s stable and reliable chassis system is applicable to diversified severe working conditions.
● The product features long ground length, high ground clearance, stable driving, and good trafficability.
● The straight tilting blade, U-blade, angle blade, coal blade, rock blade, environmental sanitation blade, ripper, and
traction frame can be installed depending on specific working condition to achieve higher working adaptability. The optional LED working lamps improve the illumination capability during nighttime operations to achieve higher safety and reliability.
Easy maintenances
● The structural parts inherit the excellent quality of Shantui’s mature products;
● The electric harnesses adopt corrugated pipes for protection and deconcentrators for branching, featuring high protection grade.
● The openable large-space side hoods make the repairs and maintenance easier.
● The fuel filter element and the air filter are designed on one same side to achieve one-stop；
● The structural parts inherit the excellent quality of Shantui’s mature products;
● The electric harnesses adopt corrugated pipes for protection and deconcentrators for branching, featuring high protection grade.
● The openable large-space side hoods make the repairs and maintenance easier.
● The fuel filter element and the air filter are designed on one same side to achieve one-stop；
Workshop Display
Exhibition
Successful Project
Project in Thailand
Project in India
Project in Russia
FAQ
Q1. What is your terms of payment?
A: 1.T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the
balance.
2. L/C at sight is acceptable too.
Q2. What is your terms of delivery?
A: FOB, CFR, CIF.
Q3. How about your delivery time?
A: Generally, it will take 15-30 days after receiving your advance payment. The specific delivery time depends on the items and
the quantity of your order. Sometimes we have some in stock.
Q4. Are you interested in dealership with local company?
A: Yes, we are quite interested in this business. We'd like to cooperate with some local partner to sell more World machines in local market and supply better service.
Q5. What is your warranty policy?
A: We can supply one year warranty for our machines. We will provide parts as free within warranty. We can send engineer to customer place if big quality problem. We can provide internet or calling service at any time.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
A: 1.T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the
balance.
2. L/C at sight is acceptable too.
Q2. What is your terms of delivery?
A: FOB, CFR, CIF.
Q3. How about your delivery time?
A: Generally, it will take 15-30 days after receiving your advance payment. The specific delivery time depends on the items and
the quantity of your order. Sometimes we have some in stock.
Q4. Are you interested in dealership with local company?
A: Yes, we are quite interested in this business. We'd like to cooperate with some local partner to sell more World machines in local market and supply better service.
Q5. What is your warranty policy?
A: We can supply one year warranty for our machines. We will provide parts as free within warranty. We can send engineer to customer place if big quality problem. We can provide internet or calling service at any time.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
