18hp small petrol engine 9kw 420cc gasoline for concrete cutter use

Описание и отзывы

Трекер стоимости

Характеристики



Hot sale! 7hp petrol engine

1) Horizontal shaft
2) Oil alert
3) All models are counter balanced for high speed  operation

4) safe handling





Model	JP168 GX160	JP168-2 GX200	JP170 GX210	JP173 GX240	JP177 GX270	JP182 GX340	JP188 GX390	JP190 GX420
Engine Type	Air-cooled, 4-Stroke, OHV, single cylinder, Gasoline Engine
Bore x Stroke [mm]	68*45	68*54	70*54	73*58	77*58	82*64	88*64	90*66
Displacement Capacity [cc]	163	196	209	242	270	337	389	420
Compression Ratio	8.5 : 1	8.5 : 1	8.5 : 1	8.2 : 1	8.2 : 1	8.0 : 1	8.0 : 1	8.0 : 1
Net Horse Power Output [hp]	5.5	6.5	7.0	8.0	9.0	11.0	13.0	15.0
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Ignition System	Transistorized magneto ignition
Starting System	Recoil or Recoil/12V Electric
Carburetor	Horizontal type butterfly valve
Lubrication System	Forced splash
Governor System	Centrifugal mechanical
Air Cleaner	Dual element type (opt Cyclone type)
Oil Capacity [Liter]	0.6	0.6	0.6	1.1	1.1	1.1	1.1	1.1
Fuel Tank Capacity [liter]	3.1	3.1	3.1	5.3	5.3	6.1	6.1	6.1
Balancing System	Single, Counter-Rotating, Balancer Shaft
Length [mm]	305	321	321	380	380	380	405	542
Width [mm]	341	376	376	430	430	430	450	500
Height [mm]	318	335	335	410	410	410	443	507
Dry Weight (Recoil start) [kg]	13	16	17	25	26	30	31	33





Any requirement,please send us an inquiry,we will reply you immediately!
