Импульсный источник питания 600 Вт 12 В 24 36 48 переменного тока в постоянный ток с цифровым дисплеем регулируемый тестер напряжения постоянного 50 А 25
- Категория: Power Supplies >>>
- Поставщик: Yueqing,City,Zhijiu,Electric,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 26.97 $* | 27.17 $* |
| Aug-19-2025 | 26.49 $* | 27.63 $* |
| Jul-19-2025 | 22.79 $* | 23.87 $* |
| Jun-19-2025 | 26.32 $* | 27.88 $* |
| May-19-2025 | 22.18 $* | 23.29 $* |
| Apr-19-2025 | 25.16 $* | 26.38 $* |
| Mar-19-2025 | 25.13 $* | 26.53 $* |
| Feb-19-2025 | 25.88 $* | 26.41 $* |
| Jan-19-2025 | 24.4 $* | 25.91 $* |
Характеристики
In order saving the power supply lifetime, the load power should at 80% of the rated power, such as when you use the 500W item, the load power should at 500W*80%=400W.
For the max output voltage, if you order 0-48V 12.5A, when you set the output voltage at 24V, the max output still is 12.5A.
switching power supply
output power: 600w
Input voltage: 110/220vac selected by switch.
Output voltage all range adjustable
Feature&Advantages:
1. High efficiency, high reliability and low cost
2. Switch input voltage range choice
3. 100% full load and machine test
4. Protection characteristics: short circuit/overloa
5. Cooling by fan
For the max output voltage, if you order 0-48V 12.5A, when you set the output voltage at 24V, the max output still is 12.5A.
switching power supply
output power: 600w
Input voltage: 110/220vac selected by switch.
Output voltage all range adjustable
Feature&Advantages:
1. High efficiency, high reliability and low cost
2. Switch input voltage range choice
3. 100% full load and machine test
4. Protection characteristics: short circuit/overloa
5. Cooling by fan
Model Specification | S-600-36 | S-600-12 | S-600-15 | S-600-24 | S-600-50 | ||||
DC Output voltage | 36v | 12V | 15V | 24V | 50V | ||||
Output voltage range(Note:2) | ±2% | ±1% | ±1% | ±1% | ±1% | ||||
Rated output current | 16A | 50A | 40A | 25A | 12A | ||||
Output voltage range DC | 0~36v | 0~12V | 0~15V | 0~24V | 0~50V | ||||
Wave and noise(Note:3) | 75mVp-p | 120mVp-p | 150mVp-p | 240mVp-p | 240mVp-p | ||||
Inlet stability(Note:4) | ±0.5% | ±1% | ±1% | ±1% | ±1% | ||||
Load stability(Note:5) | ±1% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ||||
DC output power | 600W | 600W | 600W | 600W | 600W | ||||
Efficiency | 86% | 83% | 84% | 86% | 87% | ||||
AC input voltage range | 100-132VAC/190-240VAC selected by switch 47-63Hz | ||||||||
Input current | 5A/230V | ||||||||
Power factor | 0.65 - 0.75 | ||||||||
AC Inrush current | 46A/230V | ||||||||
Leakage current | <3.5mA/240VAC | ||||||||
Overload protection | 120%-150% Reset: auto recovery | ||||||||
Over-voltage protection | 120%-150% | ||||||||
High-temperature protection | ERH3≥65°C~70°CFan on, ≤55°C~60°CFan off, ≥80°C~85°C, Cut off output (5-15V)~(24-48V) | ||||||||
Temperature coefficient | ±0.03%/°C(0~50°C) | ||||||||
Setup, rise, hold up time | 1s, 100ms, 50ms | ||||||||
Vibration | 10~500Hz, 2G 10min,/1 cycle. Period for 60min, Each axes | ||||||||
Withstand voltage | I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC | ||||||||
Isolation resistance | I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC | ||||||||
Working temperature and humidity | -10°C~+60°C, 10%~95%RH | ||||||||
Store temperature and humidity | -20°C~+85°C, 10%~95%RH | ||||||||
Overall dimension | 215*115*50mm (L*W*H) | ||||||||
Weight | 1.0Kgs | ||||||||
Safety standards | GB4949,UL60950,EN60950 | ||||||||
EMC standards | According to GB9254 EN55022 EN55024 A level design | ||||||||
Applications
1. How we control the quality?
Aging test for 8 hours, after then we put them into the market.
2. Can we accept samples customized?
No problem for samples order, and welcome your testing before your big order.
3. What about the production capacity?
4 days for samples order under 100pcs, 7-15 days for general order under 10000pcs.
4. OEM and ODM are available?
Yes, we accept customized products
5. Will the delivery time be long for a big order?
No, we have two special parts in production line, one for samples orders, another for big orders, so we can control the delivery time as we promise in the contract.
6. What is our warranty service?
For all products we sell have 2 year warranty.
