Factory direct sales Buffered Fiber Optics 100vm 0.22 NA UV/VIS 10m
- Категория: >>>
- Поставщик: Qinhuangdao,Intrinsic,Crystal,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 60.56 $* | 63.48 $* |
| Aug-17-2025 | 59.18 $* | 62.62 $* |
| Jul-17-2025 | 50.42 $* | 53.98 $* |
| Jun-17-2025 | 58.77 $* | 61.69 $* |
| May-17-2025 | 51.61 $* | 54.89 $* |
| Apr-17-2025 | 57.35 $* | 60.47 $* |
| Mar-17-2025 | 57.17 $* | 60.69 $* |
| Feb-17-2025 | 56.72 $* | 59.32 $* |
| Jan-17-2025 | 56.59 $* | 59.40 $* |
Характеристики
Products Show
UV/VIS Optical Fibers
* High OH Content
* Fused Silica Core
* Stepped Index
* Multimode Fiber
VIS/NIR Optical Fibers
* Low OH Content
* Ideal for Use with NIR Diode Lasers
* Fused Silica Core
* Stepped Multimode Fiber
* High OH Content
* Fused Silica Core
* Stepped Index
* Multimode Fiber
VIS/NIR Optical Fibers
* Low OH Content
* Ideal for Use with NIR Diode Lasers
* Fused Silica Core
* Stepped Multimode Fiber
Product Paramenter
Acceptance Angle (°): | 25.4 |
Buffer Material: | Polyimide |
Cladding Diameter (μm): | 125 +1/-3 |
Coating: | UV/VIS |
Minimum Bend Radius (mm): | 25/13 (Continuous/Momentary) |
Substrate: | Fused Silica |
Length (m): | 25.00 |
Numerical Aperture NA: | 0.22 |
Operating Temperature (°C): | -190 to +390 |
Outer Diameter (μm): | 145 ±5 |
Core Diameter (μm): | 50 ±2 |
Index of Refraction nd - Core: | 1.457 |
Index of Refraction nd - Cladding: | 1.439 |
Wavelength Range (nm): | 190 - 1250 |
Company Profile
Exhibition Display
Certificate Display
Shipping Methods
FAQ
1. Product choosing
Our company have the large quantity of standard products in our stocks. Customer can choose the products according to the
acquirement, such as size, technical data and Coating characteristics. Also, we can produce the special optical products according
customers’ demand.
2. Product preserving
Optical components should be protected with dry situation and suitable temperature without being used. Please clean it with gauze
and cotton dipped in special cleaner (20% anhydrous alcohol + 80% ether mixture)
3. Quality assurance
Please check out the products when you received with the courier being attendance. Within 30 days after receiving the products,
you can contact me freely and provide your testing report if there is something unartificial damage and disqualification technical
data. We will be responsible for free charge repairmen, change and return.
4. Payment terms
The payment terms can be flexible and can be cash, T/T and Paypal.
5. Delivery terms
We can deliver stock products within 7 work days, and within promissory delivery time for customized products.
Our company have the large quantity of standard products in our stocks. Customer can choose the products according to the
acquirement, such as size, technical data and Coating characteristics. Also, we can produce the special optical products according
customers’ demand.
2. Product preserving
Optical components should be protected with dry situation and suitable temperature without being used. Please clean it with gauze
and cotton dipped in special cleaner (20% anhydrous alcohol + 80% ether mixture)
3. Quality assurance
Please check out the products when you received with the courier being attendance. Within 30 days after receiving the products,
you can contact me freely and provide your testing report if there is something unartificial damage and disqualification technical
data. We will be responsible for free charge repairmen, change and return.
4. Payment terms
The payment terms can be flexible and can be cash, T/T and Paypal.
5. Delivery terms
We can deliver stock products within 7 work days, and within promissory delivery time for customized products.
