304 SS воздушная душевая кабина для 1-2 человек

Описание и отзывы

Трекер стоимости

Характеристики

304 SS airlock room air shower for 1-2 people



Type: Full Stainless Steel Air Shower
Outside Dimension (mm):1400W×1000D ×2100H
Dimension of Air Shower Area (mm):800W×900D×1960H
Applicable Number of People:1 person
Materials: All Full Set Stainless SUS304 or coated cold rolled steel
Number of Nozzle:12(Two Sides) Stainless Steel 304
Mouth Diameter of Nozzle:Φ30mm
Control panel:sus304 frame,LCD display, PLC control system
Speed of Air Flow at the Nozzle:>28m/s
Dimension of High Efficiency Air Filter (mm):600×600 ×120
Lock:Electronic Interlock,two door can't open at the same time.
Pre-Filter:600*350*10(mm),2PCs,synthetic fiber with aluminum
HEPA Filter:2PCs,600*600*120(mm),
FAN:2PCs,Power:0.55KW, Air Volume:1000/PCS,Air Pressure:1200Pa
LAMP:1PCs LED light,Power:1*7W.
Shower Time:0-99s adjustment
HEPA Filter Efficiency:H13,99.995%@0.38um.
Maximum Power Consumption:1.1KW
Voltage available:380VAC / 5Phase,50HZ(can make other standard voltage)

Model	YN-S1	YN-S2	YN-S3	YN-S4
Applicable Number of People	1	2-4	4-5	5-6
Air Shower Time	0- 99s (Adjustable)
Number of Nozzle	12 (Two Sides)	24 (Two Sides)	36 (Two Sides)	48 (Two Sides)
Mouth Diameter of Nozzle	Φ 30 mm	Φ 30 mm	Φ30 mm	Φ30 mm
Speed of Air Flow at the Nozzle	>25m/s	>25m/s	>25m/s	>25m/s
Dimension of High Efficiency Air Filter (mm)	600×600×120	600 ×600×120	600×600×120	600×600×120
Dimension of Air Shower Area (mm)	800×900×196 0	800×1900×196 0	800×2900×196 0	800×3900×196 0
Outside Dimension (mm)	1400×1000×210 0	1400×2000×2100	1400×3000×2100	1400×4000×2100
Power Supply :380V,50HZ, we can made nonstandard voltage for different country.
Maximum Power Consumption	1.1KW	2.2KW	3.3KW	4.4KW
