304 Or 316L Stainless Steel Filter Bag Housing For Honey


Поделиться:


Цена:*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-17-2025 0.84 $* 0.98 $*
Aug-17-2025 0.60 $* 0.81 $*
Jul-17-2025 0.94 $* 0.84 $*
Jun-17-2025 0.12 $* 0.37 $*
May-17-2025 0.1 $* 0.12 $*
Apr-17-2025 0.37 $* 0.57 $*
Mar-17-2025 0.65 $* 0.17 $*
Feb-17-2025 0.52 $* 0.54 $*
Jan-17-2025 0.91 $* 0.69 $*

Характеристики



Product Description




Specification




Material
Housing
Stainless Steel 304 and 316 for choice
Basket
Stainless Steel 304 and 316 for choice
Gasket
Silicone, EPDM, Nitrile etc
Inlet/Outlet
Size, type and position according to customers' requirement
Vent
1/4'' NPT
Drain
1'' male or as your request
Surface finish
Electro polished or Sand blasting
Designed Pressure
9.6 bar(139psi) with in 30 mins.
Max. operating pressure
6.0bar(87psi)
Temperature
Max.115℃(Design 140℃)



Type

Model
Dimensions
(mm)

           Inlet/Outlet
          Bag

Flow Rate(m3/h)
D
H
Size
Q'ty(pc)

Single Bag Filters
BJD1
220
550

2'' Female Pipe Thread / Tri-Clamp / Flange
#1

One
20
BJD2
220
950
#2
40
BJD3
130
650
#4
12



Multi-Bag Filters
BJD2-2
400
1550



3'' Female Pipe Thread / Tri-Clamp / Flange
#2
Two
80
BJD2-3
500
1550
#2
Three
120
BJD2-4
550
1550
#2
Four
160
BJD2-5
600
1550
#2
Five
200
BJD2-6
650
1620
#2
Six
240


Order Information


Product
Bag Size
Bag Q'ty
Inlet/Outlet
Connection
Surface
Material
BJD
1-#1bag
01-Single
A-side in and side out

B-side in and bottom out

C-bottom in and bottom out

D-top in and bottom out
K-Tri-Clamp

F-Flange

S-Thread
S-Sand blasting
SUS304
2-#2 bag
02-Two
T-Polished
SUS316L
3-#3 bag
03-Three
How to order?-Example
4-#4 bag
04-Four
Bag size:#1; Bag Q'ty: Single Inlet/Outlet: side in and side out
5-#5 bag
06-Six
Connection: Tri-Clamp Surface: Polished
6-#6 bag
08-Eight
Material: SUS304
X-other size

Selection code is: BJD101AKT304


Packing & Delivery




packing with standard export carton or wood cases


Company Profile






Hangzhou Tianshan Precision Filter Material Co., Ltd. is an ISO9001:2000 certified company.

Since 2001, we have focused on manufacturing pleated membrane filter cartridges and filtration equipment. Our sincere service and excellent quality win the trust of customers. Many famous pharmaceutical groups in China choose our products to purify the water, such as:
Lijun Pharmaceutical Co., Ltd. - Listed on Hongkong with over 2,000 employees;
Harbin Pharmaceutical Group - one of the top 500 large scale groups in China.

Our main products:
1. Pleated membrane filter cartridges: PP, PES, PVDF, PTFE, nylon (PN6, PN66), ACF (activated carbon filter), melt blown filter, string wound filter, etc.
2. Antiseptic shelter filter
3. Filtration equipment: made of stainless steel (SS304, SS316)

Applications:
our products can be widely used in many industries including medicine production, food and beverage production, biological engineering, microelectronic industry, fine chemical industry, galvanization, super purification of water, sewage processing, etc.

Quality Assurance:
Complete quality management system;
Workshop organized as per pharmaceutical criterions (GMP);
Materials reach pharmaceutical grade;
Membranes are made by American companies(certificates are available);
Integrity testing;
Strictly inspected by advanced instrument before packing.

Welcome to visit us.


FAQ


1. who are we?
We are based in Zhejiang, China, start from 2001,sell to Eastern Europe(20.00%),South Asia(17.00%),Southern Europe(10.00%),Western Europe(10.00%),Southeast Asia(10.00%),Eastern Asia(10.00%),Africa(5.00%),Northern Europe(5.00%),Mid East(5.00%),South America(2.00%),Oceania(2.00%),North America(2.00%),Central America(2.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Pleated Membrane Filter Cartridges,Air filter cartridge and housing,SS Filter housings,Capsule filters,Filter membrane Rolls

4. why should you buy from us not from other suppliers?
We are a cartridge filter manufacturer with more then 16years history. With an engineer team with more then 20 year experience in Filtration industry. We manufacture our own brand TS filter and filter which equilavent to some famous brand.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,Express Delivery;
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,PayPal,Western Union;
Language Spoken:English,Chinese


Contact Us


Wechat or Whats app:+8618667135293
Email Address: ggh (at) tsjmlc.com
Contact Person: Katie Jiang
