1.5ton 2t 2.5ton3.5ton 4ton 6ton 7ton 3 тонны поднимающая груз весом до 5 тонн дизельного топлива вилочный погрузчик Автопогрузчик оптовая продажа вилка подъёмник

Описание и отзывы

Трекер стоимости

Характеристики

1.The forklift has a low center of gravity, good stability and a comfortable driver. Adjustable small-diameter steering wheel, the driver feels good, the seat can be adjusted back and forth 150mm range, the operator can choose the best driving position;

2.The damping buffer oil system, the falling speed is automatically slowed down, so that the goods and pallets do not hit the ground, effective Protect the cargo and the ground;

3.The wide-view mast is not easy to block the operator's line of sight. The size of the fork mast is increased and the field of view is wide.

4.The steering bridge and the frame joint are shock-damped, and the forklift vibration is reduced by 30%.

5.The steering angle is designed with optimized design. The maximum error angle is less than 1 degree, which reduces tire wear and improves service life.

6.The hose joints and transition joints in the pipeline are in the form of cone sealing. The sealing effect is good, no sealing ring is needed, and the long-term use will not leak oil due to the aging of the sealing ring.

Model								CPCD30
Power type								Diesel
Rated capacity							kg	3000
Load center							mm	500
Lift height							mm	3000
Free lift height							mm	130
Fork size					L*W*T		mm	1070*125*45
Fork outside spread(Min./Max)								300/1200
Mast tilt range					Front/Back		deg	6/12
Front o-verhang							mm	490
Overall dimensions		Length to face of fork					mm	2680
		Overall width					mm	1225
		Mast lowered height					mm	2095
		Overhead guard height					mm	2120
Turning radius							mm	2460
Min. right angle aisle width							mm	2105
Travel (No load/full load)							km/h	20/18.5
Lift speed							mm/s	480
Max. gradeability							%	20
self weight							kg	4400
Tires	Front							28×9-15-12PR
	Rear							6.50-10-10PR
Tread	Front						mm	1000
	Rear						mm	970
Wheelbase							mm	1700
Min. ground (no ldad/full load)				Mast			mm	152/132
				Frame			mm	158/138
Battery			Voltage				V/Ah	12/90
Engine			Model					QUANCHAI 490
			Rated output					34.5/2500
			Rated torque					139/1800
			Displacement					2369
			No.of cylinder					4
Transmission			Type					Hydraulic
			Shift			(Fwd/Rwd)		1/1
Operating pressure							Mpa	17.5
