7804 2101-3103025 6-7804 U роликовый подшипник передней ступицы для ваз 2101 VAZ-1111 Оки
- Категория: Bearings >>>
- Поставщик: Shandong,Vanlin,Bearing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.70 $* | 0.30 $* |
| Aug-20-2025 | 0.38 $* | 0.44 $* |
| Jul-20-2025 | 0.57 $* | 0.59 $* |
| Jun-20-2025 | 0.21 $* | 0.47 $* |
| May-20-2025 | 0.27 $* | 0.78 $* |
| Apr-20-2025 | 0.18 $* | 0.68 $* |
| Mar-20-2025 | 0.27 $* | 0.60 $* |
| Feb-20-2025 | 0.11 $* | 0.70 $* |
| Jan-20-2025 | 0.17 $* | 0.0 $* |
Характеристики
Specification
Product name | 7804 2101-3103025 6-7804 U Roller front hub bearing for VAZ 2101 VAZ-1111 OKA car VAZ-2102 |
Usage | VAZ 2101 VAZ-1111 OKA car VAZ-2102 |
Size | 19.058x45.25x15.494 |
Car Make | for VAZ-2103 VAZ-2105 VAZ-2106 VAZ-2107 VAZ-2101, VAZ-2102 |
Place of Origin | China |
Brand Name | VLBG |
Model Number | 7804 6-7804Y 2101-3103025 |
Warranty | 24Months |
Inner diameter | 19.058MM |
Outside diameter | 45.25MM |
Height | 15.494MM |
Bearing type | Friction bearings |
Certificate | ISO9001/TS16949 |
Roller body material | SHX15 |
Weight | 0.129 |
Number of rolling bodies | 14 |
Standard | TU 37.006.170-90 |
Roller length | 10.5 |
Type of perceived loads | Radial thrust |
Roller Body diameter | 5.82 |
Bearing specifications 7804
Inner diameter - 19.05 mm;
Outside diameter - 45.25 mm;
Width - 15,494 mm;
Weight - 0.129 kg;
The number of rollers in the bearing - 14 pcs .;
Roller dimensions - 5.82 / 6.5x15.494 mm;
Dynamic lifting capacity - 27.5 kN;
Static lifting capacity - 27.5 kN;
The maximum rated speed is 11000 rpm.
Outside diameter - 45.25 mm;
Width - 15,494 mm;
Weight - 0.129 kg;
The number of rollers in the bearing - 14 pcs .;
Roller dimensions - 5.82 / 6.5x15.494 mm;
Dynamic lifting capacity - 27.5 kN;
Static lifting capacity - 27.5 kN;
The maximum rated speed is 11000 rpm.
7804 2101-3103025 for VAZ 2101-2107
Bearing 7804 is the front bearing of the VAZ hub of models from 2101 to 2107 (outer support, bearing 7805 is placed on the inner support ), as well as the rear bearing of the Oka hub, can also be installed in the hubs of other passenger cars. It has practically no other areas of application, however, due to the fact that the above-mentioned models are still quite widespread, the demand for it is very high.
The imported analog of this type of roller bearing is designated according to the international nomenclature - K-LM11949 / K-LM11910 (designations for the inner and outer rings are different). .
The imported analog of this type of roller bearing is designated according to the international nomenclature - K-LM11949 / K-LM11910 (designations for the inner and outer rings are different). .
FAQ
Q.Are you trading company or manufacturer ?
Yes we are factory.
Q.How long is your delivery time?
Generally it is 5-10 days if the goods are in stock.
Q.Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q.What is your terms of payment ?
We can accept any way payment.
Yes we are factory.
Q.How long is your delivery time?
Generally it is 5-10 days if the goods are in stock.
Q.Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q.What is your terms of payment ?
We can accept any way payment.
7804 bearings
7804 6-7804Y single row tapered roller bearing number 2101-3103025 for vaz 2101-2107 vaz car wheel
Russian roller bearing 7804 (2101-3103025) VAZ 2101 front hub bearing
Bearing 7804 size 19.058x45.25x15.494
6-7804 VAZ-1111 OKA car Rear hub (78047205) / Front wheel hub n. (78047805)
6-7804 U Car VAZ-1111 OKA Rear wheel hubs (outer support)
6-7804U\t Car VAZ-1111 OKA rear and front wheel hubs (outer support)
6-7804 U front wheel hub bearing for Car VAZ-2101 Car VAZ-2102
VAZ 1111 "Oka"\tRear wheel hubs (outer support)\t6-7804 U
6-7804 U Passenger car Front wheel hubs bearings for VAZ-2103 VAZ-2105 \t VAZ-2106 VAZ-2107
VAZ-2101, VAZ-2102\tFront wheel hubs\t6-7804 U
6-7804 U\t VAZ-2121 Niva car Rear hub (78047205) / Front wheel hub n. (78047805)
LM11949 / 910 / Q KLM11949.LM11910 LM11949.LM11910
VAZ-2103, VAZ-2105, VAZ-2106, VAZ-2107\tFront wheel hubs\t6-7804 U
Russian roller bearing 7804 (2101-3103025) VAZ 2101 front hub bearing
Bearing 7804 size 19.058x45.25x15.494
6-7804 VAZ-1111 OKA car Rear hub (78047205) / Front wheel hub n. (78047805)
6-7804 U Car VAZ-1111 OKA Rear wheel hubs (outer support)
6-7804U\t Car VAZ-1111 OKA rear and front wheel hubs (outer support)
6-7804 U front wheel hub bearing for Car VAZ-2101 Car VAZ-2102
VAZ 1111 "Oka"\tRear wheel hubs (outer support)\t6-7804 U
6-7804 U Passenger car Front wheel hubs bearings for VAZ-2103 VAZ-2105 \t VAZ-2106 VAZ-2107
VAZ-2101, VAZ-2102\tFront wheel hubs\t6-7804 U
6-7804 U\t VAZ-2121 Niva car Rear hub (78047205) / Front wheel hub n. (78047805)
LM11949 / 910 / Q KLM11949.LM11910 LM11949.LM11910
VAZ-2103, VAZ-2105, VAZ-2106, VAZ-2107\tFront wheel hubs\t6-7804 U
7804 bearings
Tapered roller bearings 7804designed for the simultaneous perception of axial and axial loads, which allows you to expand the scope of its application and significantly simplify the design of the supporting units of mechanisms and equipment.In application Angular contact tapered roller bearing 7804 reduces the requirements for alignment, which is very important in the manufacture of products, especially large-sized ones. Mounting a single bearing provides the ability to take a radial load together with an axial load acting in one direction (paired installation, with axial bidirectional). Angular contact tapered roller bearing 7804 has a wide range of applications: in general machine building equipment, in transmissions of tractor and automotive equipment, in wheel hubs, in metalworking machine
