 AC Automatic Voltage Regulator Stabilizer AVR 220/110V 1Phase Single Phase Servo motor type high accuracy SVC-500VA/0.5KVA/1000VA/1KVA/1500VA/1.5KVA/2000VA/2KVA/3000VA/3KVA/5000VA/5KVA/7500VA/7.5KVA/10000VA/10KVA/15KVA/20KVA/30KVA/40KVA/50KVA/60KVA



1. Feature:
The series product is a servo-motor type high accuracy household AC Automatic Voltage Stabilizer regulator AVR, the low power consumption, reliable work, high accuracy of stabilization, and good for use in regions where the net voltage is much fluctuating.

2. Application:
Computer, Test equipment, Lighting system, Communication system, Medical equipment, Industrial automatic equipment, Stereo sound equipment and Home or office appliance etc.

3. Specification:
Phase No.: Single phase/1 Phase
Input voltage: Customized super low input voltage, wide input range: 70~250V
Output voltage: 220VAC/110VAC(0.5kVA~3kVA); 220VAC(5kVA~60kVA)
Accuracy of voltage: +/-2.5%
Frequency: 50Hz/60Hz
Efficiency: >90%
Response time: <1.5s against 10% input voltage deviation
Ambient Temperature: -10C~+40C
Insulation resistance: >2MΩ
Waveform distortion: Non-additional waveform distortion
Protection function: Over voltage, over current, overloading and delay etc.

4. Remarks:
Custom-made specifications are acceptable.



5. Models:

Model	Rated Power	Package Size(Approx. )	Qty. Per Pkg
SVC-500VA	500VA	25*44*35CM	4PCS/PKG
SVC-1000VA	1000VA	28*50*40CM	4PCS/PKG
SVC-1500VA	1500VA	28*50*40CM	4PCS/PKG
SVC-2000VA	2000VA	35*61*27CM	2PCS/PKG
SVC-3000VA	3000VA	36*58*30.5CM	2PCS/PKG
SVC-5000VA(Desk type)	5000VA	29*53*23CM	1PC/PKG
SVC-7500VA(Desk type)	7500VA	55*37.5*29.5CM	1PC/PKG
SVC-10000VA(Desk type)	10000VA	55*37.5*29.5CM	1PC/PKG
SVC-5KVA(Vertical type)	5KVA	31*34*52CM	1UNIT/PKG
SVC-7.5KVA(Vertical type)	7.5KVA	31*34*52CM	1UNIT/PKG
SVC-10KVA(Vertical type)	10KVA	31*34*52CM	1UNIT/PKG
SVC-15KVA	15KVA	49.5*46.5*82CM	1UNIT/PKG
SVC-20KVA	20KVA	49.5*46.5*82CM	1UNIT/PKG
SVC-30KVA	30KVA	51.5*50.5*95CM	1UNIT/PKG
SVC-40KVA	40KVA	75*64*112CM	1UNIT/PKG
SVC-50KVA	50KVA	75*64*112CM	1UNIT/PKG
SVC-60KVA	60KVA	75*64*112CM	1UNIT/PKG
