ISO2531 синяя эпоксидная 100 мм труба с фланцем из ковкого чугуна
US $600.00-$850.00
Труба из ковкого чугуна K9 класса k7 150 мм поставщик быстрая доставка оптовая
- Категория: Iron Pipes >>>
- Поставщик: Shandong,Hongzheng,Metal,Products,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 417.64 $* | 438.54 $* |
| Aug-18-2025 | 413.75 $* | 434.73 $* |
| Jul-18-2025 | 347.91 $* | 364.34 $* |
| Jun-18-2025 | 406.78 $* | 426.8 $* |
| May-18-2025 | 354.2 $* | 372.20 $* |
| Apr-18-2025 | 399.88 $* | 419.64 $* |
| Mar-18-2025 | 396.34 $* | 416.79 $* |
| Feb-18-2025 | 392.42 $* | 412.11 $* |
| Jan-18-2025 | 389.74 $* | 408.20 $* |
Характеристики
Specification
item | value |
Place of Origin | ShangDong china |
Brand Name | hongzheng |
Model Number | EN598 DN80 DN1200 ISO2531 |
Length | 6-12M |
Standard | ISO2531/EN545/EN598 |
Application | Drinking water/sewage water |
Shape | Round |
Hardness | 230HB |
Pipe Wall Thickness | K7/K8/K9/C40/C30/C25 |
Pull Strength | 420Mpa |
Yield (≥ MPa) | 600 |
Material | Ductile Iron |
Type | casting |
Processing Service | Welding, Bending, Punching, Decoiling, Cutting |
Products Description
1) The standard of pipe: ISO 2531, EN545 , EN598.
2) Pipe class: K9, C40, C30, C25, etc.
3) Pipe joint: push-on joint(Tyton joint), K type joint, self-restrained joint
4) Effective length: in general, the pipe length is 6m for bulk shipment and 5.7m for container shipment.
5) Internal lining: cement mortar lining as per ISO4179
6) Zinc coating: at least 130g/m2 as per ISO 8179
7) Bitumen painting: at least 70um as per ISO 8179
8) Gaskets are NBR rubber, natural rubber, SBR rubber or EPDM rubber ring as per ISO4633
2) Pipe class: K9, C40, C30, C25, etc.
3) Pipe joint: push-on joint(Tyton joint), K type joint, self-restrained joint
4) Effective length: in general, the pipe length is 6m for bulk shipment and 5.7m for container shipment.
5) Internal lining: cement mortar lining as per ISO4179
6) Zinc coating: at least 130g/m2 as per ISO 8179
7) Bitumen painting: at least 70um as per ISO 8179
8) Gaskets are NBR rubber, natural rubber, SBR rubber or EPDM rubber ring as per ISO4633
Process and testing:
1. a) Induction furnace and treated metal (Chemical analysis of raw material, spheroidizing & Nodularity)
2. b) Casting (Visual check and weight check)
3. c) Heat treatment (Micro structure)
4. d) Hydrostatic test (Pressure test)
5. e) Dimensional checks (Checking pipe length and joint, OD, wall thickness, appearance)
6. f) Zinc spraying (Thickness testing)
7. g) Lining and coating (100% visual check, thickness testing randomly)
8. i) Marking and packing (100% visual check)
1. a) Induction furnace and treated metal (Chemical analysis of raw material, spheroidizing & Nodularity)
2. b) Casting (Visual check and weight check)
3. c) Heat treatment (Micro structure)
4. d) Hydrostatic test (Pressure test)
5. e) Dimensional checks (Checking pipe length and joint, OD, wall thickness, appearance)
6. f) Zinc spraying (Thickness testing)
7. g) Lining and coating (100% visual check, thickness testing randomly)
8. i) Marking and packing (100% visual check)
Application
Packaging & Shipping
Packing and shipping
1.Export sea worthy package + water proof paper + wooden pallet
2.Max Loading 26.5mt for each 20Gp container
3.Safe loading and fixing Professional teams
4.Professional shipping line Delivery:
5-7 days after confirming the order or according to your order quantity Port of shipment:shanghai qingdao tianjin
client feedback
Company Profile
FAQ
1. Q: who are we?
A: We are based in Shandong, China, we have 15 industrial steel history, There are total about 100 people in our factory.
2. Q: how can we guarantee quality?
A: Always a pre-production sample before mass production; Always final Inspection before shipment;
3. Q: Can we visit your factory?
A: Warmly welcome. Once we have your schedule, we will arrange the professional sales team to follow up your case.
4. Q: How is your Payment Term?
A: We prefer TT or according to your requirements
5 .Q: Can provide OEM/ODM service?
A: Yes. Please feel free to contact us for more details discuss.
6.Q: Can you provide sample?
A: Yes, for regular size of samples, it's for free but buyer need to pay freight cost.
7.Q: What's the MOQ ?
A: 25Tons is ok
8.Q: What's your delivery time ?
A: Regular lead time is 7-15days after receiving deposit
9. We have full stock,and can deliver within short time.Many styles for your choices. After you choose
1. We will count cheapest shipping cost and make invoice to you at once.
2. Check quality again, then send out to you at 1-2 working day after your payment,
3. Email you the tracking no, and help to chase the parcels until it arrive you. After-sale choose
1. We are very glad that customer give us some suggestion for price and products.
2. If any question,please contact with us freely by E-mail or Telephone.
