Быстрая доставка башенного крана T2850-120V 85m 120 тонны низкий-натриевый вкладыш
- Категория: Tower Cranes >>>
- Поставщик: Maxizm,Construction,Machinery,(Qingdao),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 130900.71 $* | 137445.86 $* |
| Aug-16-2025 | 129800.27 $* | 136290.84 $* |
| Jul-16-2025 | 108900.34 $* | 114345.27 $* |
| Jun-16-2025 | 127600.77 $* | 133980.94 $* |
| May-16-2025 | 111100.58 $* | 116655.41 $* |
| Apr-16-2025 | 125400.97 $* | 131670.66 $* |
| Mar-16-2025 | 124300.35 $* | 130515.24 $* |
| Feb-16-2025 | 123200.61 $* | 129360.33 $* |
| Jan-16-2025 | 122100.4 $* | 128205.13 $* |
Характеристики
Contact
Send Message or Chat Now for Best price
Audrey Zhang
Mobile: +86 17854220375
Maxizm Construction Machinery(Qingdao) Co.,Ltd.
Please let us know the main use, brand, power and other requirements of the purchased products.
We will recommend the related products to you.
Mobile: +86 17854220375
Maxizm Construction Machinery(Qingdao) Co.,Ltd.
Please let us know the main use, brand, power and other requirements of the purchased products.
We will recommend the related products to you.
Flat-top Tower Crane
Products Description
China top brand Flat-top Tower Crane T2850-120V with High Efficiency
• Max. jib length: 85m; Jib length under different assembling modes can decrease progressively by 5 meters and the Min. jib length
is 50 meters.
• Max. lifting capacity 120t;
• Hoisting capacity at jib tip:27t;
• Max. lifting moment 2850 t.m;
• Hoisting mechanism:H132FL150-1230-D; power: 132kW; rope capacity:1230m;
• Slewing mechanism:HP185F1.350A/HP185F2.350A; power: 4×18.5kW(85m jib), 3×18.5kW（others）;
• Trolleying mechanism: T185FC85; power:18.5kW
• Types of tower crane: stationary crane with embedded outriggers, stationary crane with embedded bolts, stationary crane with
under-frame and mobile tower crane.
• Max. jib length: 85m; Jib length under different assembling modes can decrease progressively by 5 meters and the Min. jib length
is 50 meters.
• Max. lifting capacity 120t;
• Hoisting capacity at jib tip:27t;
• Max. lifting moment 2850 t.m;
• Hoisting mechanism:H132FL150-1230-D; power: 132kW; rope capacity:1230m;
• Slewing mechanism:HP185F1.350A/HP185F2.350A; power: 4×18.5kW(85m jib), 3×18.5kW（others）;
• Trolleying mechanism: T185FC85; power:18.5kW
• Types of tower crane: stationary crane with embedded outriggers, stationary crane with embedded bolts, stationary crane with
under-frame and mobile tower crane.
Product Paramenters
Rated liftingmoment(t.m) | 2850 | ||||||||||||||||||||||
Max.liftingheight(m) | Free-standingstationarycrane | ||||||||||||||||||||||
67 | |||||||||||||||||||||||
Anchoredcrane | |||||||||||||||||||||||
266.5 | Workingradius(m) | ||||||||||||||||||||||
Max.workingradius | 85 | ||||||||||||||||||||||
Min.workingradius | |||||||||||||||||||||||
3.5 | |||||||||||||||||||||||
Max.liftingcapacity(t) | 120 | ||||||||||||||||||||||
Hoistingmechanism | Ropefall | α＝2 | |||||||||||||||||||||
α＝4 | α＝8 | ||||||||||||||||||||||
Speed(m/min) | 20 | 40 | 68 | 100 | 10 | 20 | |||||||||||||||||
34 | 50 | 5 | 10 | 17 | 25 | Liftingweight(t) | |||||||||||||||||
30 | 15 | 7.5 | 2 | 60 | 30 | 15 | 4 | ||||||||||||||||
120 | 60 | 30 | 8 | Power(kW) | 132 | ||||||||||||||||||
Slewingmechanism | Speed(m/min) | 0~0.38 | |||||||||||||||||||||
Power(kW) | |||||||||||||||||||||||
4×18.5kW(80mjib),3×18.5kW（others） | |||||||||||||||||||||||
Trolleyingmechanism | Speed(m/min) | ||||||||||||||||||||||
0~40 | |||||||||||||||||||||||
Power(kW) | 18.5 | ||||||||||||||||||||||
Rear axle load | kg | 26000 | |||||||||||||||||||||
