Монокристаллическая солнечная панель 450 Вт солнечные панели 445 wp монокристаллические 600
- Категория: Solar Panels >>>
- Поставщик: Hefei,Sunway,Solar,Energy,Tech.Co.,Ltd
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.49 $* | 0.54 $* |
| Aug-19-2025 | 0.63 $* | 0.75 $* |
| Jul-19-2025 | 0.25 $* | 0.9 $* |
| Jun-19-2025 | 0.9 $* | 0.75 $* |
| May-19-2025 | 0.33 $* | 0.51 $* |
| Apr-19-2025 | 0.7 $* | 0.70 $* |
| Mar-19-2025 | 0.46 $* | 0.37 $* |
| Feb-19-2025 | 0.21 $* | 0.20 $* |
| Jan-19-2025 | 0.80 $* | 0.43 $* |
Характеристики
Half Cut Technology solar panels 350 watt solar panels cost portable solar panel solar panels sudan 275w flexible solar panel 1000 watt solar panel)(transparent solar panel second hand solar panels lg solar panel 12v solar panel solar panel 300 watt paneles solares 10000 w
Under the same shadow condition, power loss of half-cell solar panel is less than that of full cell solar panel. 250 watt solar
Multi Busbar Technology (golf cart solar panel 24v solar panel 12 volt solar panel monocrystaline solar panels paneles solares chinos precio panel trina solar 800w solar panel price solar panels oman 10w solar panel solar-panel baterias para paneles solares)
MBB technology improves efficiency of modules, offers a better aesthetic appearance. (german solar panel sun power solar panel sistema de paneles solares rv solar panels 6v solar panel flex solar panel solar panels 100watt bipv solar panel solar panels 250 watt)
PERC Technology thin solar panels power bank solar panel semi flexible solar panel ae solar panel solar panel 300w 12v solar panel 280w 500watt solar panel paneles solares 300watts 40w solar panel double glass solar panels solar panel transparent)
The PERC cell has a passivated rear side and a laser grooving process, which significantly improves the cell efficiency.
Under the same shadow condition, power loss of half-cell solar panel is less than that of full cell solar panel. 250 watt solar
Multi Busbar Technology (golf cart solar panel 24v solar panel 12 volt solar panel monocrystaline solar panels paneles solares chinos precio panel trina solar 800w solar panel price solar panels oman 10w solar panel solar-panel baterias para paneles solares)
MBB technology improves efficiency of modules, offers a better aesthetic appearance. (german solar panel sun power solar panel sistema de paneles solares rv solar panels 6v solar panel flex solar panel solar panels 100watt bipv solar panel solar panels 250 watt)
PERC Technology thin solar panels power bank solar panel semi flexible solar panel ae solar panel solar panel 300w 12v solar panel 280w 500watt solar panel paneles solares 300watts 40w solar panel double glass solar panels solar panel transparent)
The PERC cell has a passivated rear side and a laser grooving process, which significantly improves the cell efficiency.
Electrical Parameters | ||||||||
Model | SW450M-144 ~ SW480M-144 | |||||||
Encapsulation | Class/Eva/Cell/Eva/Backsheet | |||||||
Maximum Power Pmax(W) | 450 | 460 | 470 | 480 | ||||
Maximum Power Voltage(Vmp/V) | 41.00 | 41.20 | 41.80 | 42.20 | ||||
Maximum Power Current(Imp/A) | 10.98 | 11.10 | 11.22 | 11.34 | ||||
Open Circuit Voltage(Voc/V) | 49.50 | 50.00 | 50.50 | 51.00 | ||||
Short Circuit Currrnt(Isc/A) | 11.42 | 11.54 | 11.60 | 11.79 | ||||
Module Efficiency(%) | 20.37 | 20.82 | 21.27 | 21.73 | ||||
Power Tolerance(W) | 0~+5W | |||||||
Temperature Coefficient of Isc(αIsc) | +0.059%/℃ | |||||||
Temperature Coefficient of Voc(βVoc) | -0.330%/℃ | |||||||
Temperature Coefficient of Pmax(γVoc) | -0.410%/℃ | |||||||
STC | Irradiance 1000w/㎡, Cell Temperature 25℃， Air Mass 1.5 | |||||||
Product Details
Multi Busbar Technology
Improve efficiency of modules,
offers better appearance.
Half Cut Technology
Under the same shadow condition,
Lower power loss than full cell.
PERC Cell Technology
120N Tensile Strength Frame
110% Seal-lip Design Glue Injection.
Frame
Tensile Strength, boost
bearing capability, prolong service life
Split Junction Box
Reduced internal power loss,
ensures module running safety
Waterproof Label
Acceptable OEM,
could print your logo on it
Quality Control
Product Packaging
Model (solar panels cost 275w flexible solar panel ) | (monocristaline solar panel) SW480M-144 (sunpower solar panel) |
Modules per box (second hand solar panels ) | 30 pieces |
Modules per 40' container (paneles solares 10000 w ) | 660 pieces |
Note: The above packing information contained is subject to change without notice. We accept any customized packing according to your needs.
