Емкость 50 T/H горнодобывающая промышленность Placer Золотой обогатительной фабрики роторный экран бутары Золота сепаратор/дробилка для переработки в
- Категория: Vibrating Screen >>>
- Поставщик: Jiangxi,Hengchang,Mining,Machinery,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 1785.7 $* | 1874.55 $* |
| Aug-16-2025 | 1770.13 $* | 1859.46 $* |
| Jul-16-2025 | 1485.52 $* | 1559.42 $* |
| Jun-16-2025 | 1740.71 $* | 1827.96 $* |
| May-16-2025 | 1515.37 $* | 1591.26 $* |
| Apr-16-2025 | 1710.59 $* | 1796.90 $* |
| Mar-16-2025 | 1695.93 $* | 1780.58 $* |
| Feb-16-2025 | 1680.51 $* | 1764.20 $* |
| Jan-16-2025 | 1665.60 $* | 1748.36 $* |
Характеристики
1.Application Fields of 100 TPH Capacity Sand Gold Mining Trommel Screen Alluvial Gold Washing Plant Trommel with Vibrating Sluice Box:
Our Trommel screen & Drum Sieve is suitable for various properties of screening materials such as: sand gold mines, coal coke,lime and damp easily blocked material, the final size after screen (the biggest size: 100mm, the middle size: 10-50mm, the finest size: <=3mm).
The circular vibration screen is widely applied to the industries such as mining, building materials, thermal power plant, and chemical industry, etc.
1) Quarry: suitable for screening and classifying gravel, clay, mountain meal, sand, etc.
2) Coal Industry: suitable for screening and classifying lump coal, coal dust, coal washing, etc.
3) Chemical,: fertilizer industry etc.
4) Mineral-selecting Industry: suitable for grading and classifying lump, powder substance, etc.
5) Metallurgy, construction, building materials, abrasives, and other industries.
2.Introduction of 100 TPH Capacity Sand Gold Mining Trommel Screen Alluvial Gold Washing Plant Trommel with Vibrating Sluice Box:
Trommel Screen is lifted up by the rotation and aerated as it falls back down. This action is repeated with each revolution along the length of the drum. The finer material passes through the screen openings while the larger material tumbles towards its eventual exit at the rear of the drum.
Our Trommel screen & Drum Sieve is suitable for various properties of screening materials such as: sand gold mines, coal coke,lime and damp easily blocked material, the final size after screen (the biggest size: 100mm, the middle size: 10-50mm, the finest size: <=3mm).
The circular vibration screen is widely applied to the industries such as mining, building materials, thermal power plant, and chemical industry, etc.
1) Quarry: suitable for screening and classifying gravel, clay, mountain meal, sand, etc.
2) Coal Industry: suitable for screening and classifying lump coal, coal dust, coal washing, etc.
3) Chemical,: fertilizer industry etc.
4) Mineral-selecting Industry: suitable for grading and classifying lump, powder substance, etc.
5) Metallurgy, construction, building materials, abrasives, and other industries.
2.Introduction of 100 TPH Capacity Sand Gold Mining Trommel Screen Alluvial Gold Washing Plant Trommel with Vibrating Sluice Box:
Trommel Screen is lifted up by the rotation and aerated as it falls back down. This action is repeated with each revolution along the length of the drum. The finer material passes through the screen openings while the larger material tumbles towards its eventual exit at the rear of the drum.
Model | Capacity (t/h) | Power (kw) | Screen diameter | Screen | Discharge size | Dimension (LxWxH) (mm) | Weight (kg) |
GT1015 | 50 | 4 | 1000mm | 1500mm | 3-10 | 3000x1400x2145 | 2200 |
GT1020 | 100 | 5.5 | 1000mm | 2000mm | 3-10 | 3460x1400x2145 | 2800 |
GT1225 | 160 | 7.5 | 1200mm | 2500mm | 3-10 | 4146x1600x2680 | 4200 |
GT1530 | 250 | 11 | 1500mm | 3000mm | 3-10 | 4460x1900x2820 | 5100 |
GT1545 | 350 | 15 | 1500mm | 4500mm | 3-10 | 5960x1900x3080 | 6000 |
GT1848 | 450 | 22 | 1800mm | 4800mm | 3-10 | 6500x2300x4000 | 7500 |
GT2055 | 600 | 30 | 2000mm | 5500mm | 3-10 | 7500x2500x4000 | 8600 |
Name | |
Capacity | <10 TPH |
screen mesh | 3-10 mm |
Warranty Period | 1 year |
Power | 3 KW |
lead time | 20 days |
