Лазерный сварочный аппарат JQ горячая Распродажа 1 кВт 5 2 для волоконно-лазерной сварки
- Категория: Laser Welders >>>
- Поставщик: Jinan,Jinqiang,Laser,Cnc,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 8187.77 $* | 8596.9 $* |
| Aug-19-2025 | 8118.83 $* | 8524.48 $* |
| Jul-19-2025 | 6811.73 $* | 7152.53 $* |
| Jun-19-2025 | 7981.97 $* | 8380.73 $* |
| May-19-2025 | 6949.3 $* | 7296.40 $* |
| Apr-19-2025 | 7843.75 $* | 8235.74 $* |
| Mar-19-2025 | 7774.8 $* | 8163.9 $* |
| Feb-19-2025 | 7706.39 $* | 8091.53 $* |
| Jan-19-2025 | 7637.80 $* | 8019.78 $* |
Характеристики
Product Description
Laser welding is a high-energy-density laser beam as a heat source, which locally heats the material in a small area and melts the material to form a specific molten pool to achieve the effect of welding. Laser welding is mainly used for welding of thin-wall materials, precision parts, etc., which can realize spot welding, splicing welding, seal welding, overlap welding, etc. The heat distortion is small, the weld seam is beautiful and smooth, and the weld seam quality is high, and no secondary grinding treatment is required. In recent years, laser welding has been widely used for welding stainless steel, carbon steel, galvanized sheet, copper, aluminum and other products.
Product Show
Fiber Laser
1500W BWT laser, long warranty of three years
High quality beam, high power stability, stable system
20μm fiber core diameter, higher electro-optical conversion efficiency
High quality beam, high power stability, stable system
20μm fiber core diameter, higher electro-optical conversion efficiency
Oscillating welding head
Width of weld bead is about 0.5mm-5mm
An anti-reflective design is added to the laser head, which is more suitable for welding of high-reflective materials, such as aluminum, and can extend the service life of the focusing lens and the laser.
Infrared positioning, more accurate welding position
An anti-reflective design is added to the laser head, which is more suitable for welding of high-reflective materials, such as aluminum, and can extend the service life of the focusing lens and the laser.
Infrared positioning, more accurate welding position
Dual temperature chiller
Intelligent temperature control, compressor cooling
LED screen, temperature display at all times
Simple to operate, stable performance, energy-saving and efficient
LED screen, temperature display at all times
Simple to operate, stable performance, energy-saving and efficient
Wire feeding device (independent feeding device is optional)
Automatic wire feeding device
Software controlled, adjustable wire feed speed
Filling the welding seam and increasing the welding strength
Software controlled, adjustable wire feed speed
Filling the welding seam and increasing the welding strength
Overall size
Laser welding is a kind of processing method of welding materials with high energy density laser beam as heat source. It has the advantages of simple operation, beautiful weld seam, fast welding speed and no consumables.
Product Paramenters
NO. | Item | Parameter | Unit |
1 | Model name | Handle laser welding machine | |
2 | Model type | JQ-HW-1500W | |
3 | Laser Power | 1500 | W |
4 | Laser wavelength | 1070 | nm |
5 | Fiber core diameter | 50 | μm |
6 | Fiber length | 10 | m |
7 | Laser working mode | Continuous / Modulation | |
8 | Galvanometer width | 0.5-6 | mm |
9 | Galvo scan speed | ≤8000 | mm/s |
10 | Welding speed | 0-120 | mm/s |
11 | Refrigeration unit | Intelligent dual temperature chiller | |
12 | Working environment temperature range | 15-35 | ℃ |
13 | Humidity range of working environment | ＜ 70% non-condensing |
Sample
Company Profile
Laser change the world
Jinan Jinqiang Laser CNC Equipment Co., Ltd. was established in 2006. It is a high-tech industry focusing on laser application and sheet metal automation complete equipment research and development, production and sales. The company's products are divided into five series: tube laser cutting machine, sheet laser cutting machine, laser engraving, laser marking, and laser welding.
JQ Laser currently has more than 200 employees, technology research and development and after-sales service account for more than 50%; we have a professional quick response customer service team, providing 24-hour online and offline technical services in 12 languages.
Now JQ Laser exports to more than 100 countries and regions around the world relies on reliable product quality, reasonable price and perfect after-sales service system.
Now JQ Laser exports to more than 100 countries and regions around the world relies on reliable product quality, reasonable price and perfect after-sales service system.
Exhibition
EXHIBITION
Listening carefully to customers' needs and making laser tube cutting machines that meet the needs of most customers is the product direction that Jinqiang Laser has been pursuing.
JQ adopts the twin-engine power model of coming from the customer site and going to the customer site, driving R&D with the market and driving the market with R&D.
Jinqiang laser R & D technical team accounts for more than 20% of the total number of people in the whole division.
JQ adopts the twin-engine power model of coming from the customer site and going to the customer site, driving R&D with the market and driving the market with R&D.
Jinqiang laser R & D technical team accounts for more than 20% of the total number of people in the whole division.
Details&Parts
Certifications
FAQ
Q: Do you have CE document and other documents for customs clearance?
A: Yes, we have CE, Provide you with a one-stop service.At first we will show you and and after shipment we will give you CE/Packing list/Commercial Invoice/ Sales contract for customs clearance.
Q: Why the machine price not include fiber source?
Different customers, different requirements, and many different laser power can be optional, that's why we list the price not include fiber source parts.
Q: If we are interested in your machine, how to choose proper power?
Please tell us the following answer, our professional seller will recommend you proper power.
1. What material you want to cut,stainless steel,carbon steel or other?
2. What thickness do you want to cut?
Q:How can I do if the laser cutting machine goes wrong?
A: If confronted with such problems, please contact us asap and do not try
fix the machine by yourself or someone else. We will response within 24 hours as quick as we can to solve it for you.
Q: How about warranty?
A: 3 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge(some parts
will be maintained) when if any problem during the warranty period.
Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the
world, We need your machines running in order to keep your business running
A: Yes, we have CE, Provide you with a one-stop service.At first we will show you and and after shipment we will give you CE/Packing list/Commercial Invoice/ Sales contract for customs clearance.
Q: Why the machine price not include fiber source?
Different customers, different requirements, and many different laser power can be optional, that's why we list the price not include fiber source parts.
Q: If we are interested in your machine, how to choose proper power?
Please tell us the following answer, our professional seller will recommend you proper power.
1. What material you want to cut,stainless steel,carbon steel or other?
2. What thickness do you want to cut?
Q:How can I do if the laser cutting machine goes wrong?
A: If confronted with such problems, please contact us asap and do not try
fix the machine by yourself or someone else. We will response within 24 hours as quick as we can to solve it for you.
Q: How about warranty?
A: 3 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge(some parts
will be maintained) when if any problem during the warranty period.
Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the
world, We need your machines running in order to keep your business running
