Лилин высокое качество LSB-450L оборудование для производства по магазинам или хлеба бумажные пакеты штранг-прессования
- Категория: Packaging Material Making Machine >>>
- Поставщик: Ruian,Lilin,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 143752.24 $* | 150940.27 $* |
| Aug-16-2025 | 142544.5 $* | 149671.32 $* |
| Jul-16-2025 | 119592.8 $* | 125572.53 $* |
| Jun-16-2025 | 140128.35 $* | 147134.14 $* |
| May-16-2025 | 122008.80 $* | 128108.58 $* |
| Apr-16-2025 | 137712.3 $* | 144598.32 $* |
| Mar-16-2025 | 136504.64 $* | 143329.96 $* |
| Feb-16-2025 | 135296.92 $* | 142061.65 $* |
| Jan-16-2025 | 134088.72 $* | 140792.54 $* |
Характеристики
Products Description
Lilin High Quality LSB-450L Equipment for the production of shopping or bread paper bags paper bag making machine ce
Introduction：
Roll Feeding square bottom paper bag making machine forming the paper bag in one process from printed or unprinted roll paper , side gluing, roll folding, roll paper cutting, bottom folding, bottom gluing, bottom forming, bag formation at a stroke. This machine controls by PC programmable servo motor through the human-machine touch screen interface. It can produce various of specifications paper bags. This machine have advantages of high speed, quickly replace the paper bag specifications, more wide range adjusting etc. It is an ideal machine for producing food bag, shopping handles bag.
Features：
1.The human-machine touch screen interface, the work condition can be shown in real- time.
2.Equipped with accurate servo motor drive, it makes the machine run steadily and efficiently.
3.Pneumatic paper reel lifting device make paper reel changing easy.
4.automatic constant tension control system. The tension will be just right from beginning to end.
5.Double photoelectric sensor limit automatic correction control system and deviation rectification stability, energy saving, long life.
6.Rotary serrated cutter (or flat-blade cutter) with elliptical gears is used for cutting, Thumb buttons, appressed bottom cutting device, bag type have many choices.
7.Don't stop machine side clamp, CAM synchronous adjustment of structure, the adjustment will become more intuitive, more simple, more time saving.
8.Glue roller air defense coating control, avoid gluing on besmear brushs hub surface directly, reduce unnecessary trouble.
9.Accurate colors tracking system, replace the paper roll, downtime, blackouts, without human intervention, the machine will automatically positioning operation, color errors automatically shut down.
10.Automatic lubricating oil supply system.
3.Pneumatic paper reel lifting device make paper reel changing easy.
4.automatic constant tension control system. The tension will be just right from beginning to end.
5.Double photoelectric sensor limit automatic correction control system and deviation rectification stability, energy saving, long life.
6.Rotary serrated cutter (or flat-blade cutter) with elliptical gears is used for cutting, Thumb buttons, appressed bottom cutting device, bag type have many choices.
7.Don't stop machine side clamp, CAM synchronous adjustment of structure, the adjustment will become more intuitive, more simple, more time saving.
8.Glue roller air defense coating control, avoid gluing on besmear brushs hub surface directly, reduce unnecessary trouble.
9.Accurate colors tracking system, replace the paper roll, downtime, blackouts, without human intervention, the machine will automatically positioning operation, color errors automatically shut down.
10.Automatic lubricating oil supply system.
Product Paramenters
Type | LSB-450L |
Bag Width (W) | 250-450 mm |
Bottom Size(H) | 90-200 mm |
Cutting Length(C) | 380-750 mm |
Bag Length(L) | L=C－(H÷2＋15~25) |
Max. Speed | 120 pcs/min |
Paper Roll Width | 750-1250 mm |
Max. reel weight | 800 Kg |
Max.Roll Diametr | 1200 mm |
Reel inner diameter | 76 mm |
Paper specification | 80-180 gsm |
Web edge control system | Double photoelectric automatic correction control system |
Web tension control system | automatic constant tension control system |
Air pressure | ≥0.12cmm, 0.4~1Mpa |
Driven motor | Double servo motor |
Electric | 380V, 50Hz, 3 phase |
Power | 12 KW |
Weight | 7300 Kg |
Overall dimension（L×W×H） | 9200×2150×1950 mm |
Company Profile
About us
Ruian Lilin machinery Co., LTD., is a professional paper bag machine manufacturer.It was founded in 2006, since its inception,the company has been committed to the r&d and production of paper bag making machine, constantly introducing new and high technology,combined with market demands and constantly develop new products, higher quality, higher efficiency to meet the market demands.Main products: LSB series roll paper square bottom paper bag machine,LSD series automatic high-speed paper bag machine, LMD series automatic high-speed paper bag machine, LST series flexo printing machine, and other paper bag related supporting products.The products have been sold to Southeast Asia and Europe. , Middle East, Africa, South America and more than 60 countries and regions. Since its inception, the enterprise always adhere to the "technology first, quality first" business philosophy, with honest and trustworthy operating style,excellent product quality and excellent service to win for the principle, for the user to achieve maximum value to reflect my value. Wholeheartedly welcome the domestic and foreign merchants to come to visit or inquire.
Certifications
Exhibition
Product packaging
FAQ
1.Are you trading company or manufacturer?
We are manufacturer, we have our own worker and factory.
2.How long has your factory been in this field?
In China, As one of the earliest manufacturers in paper bag machine, we have more than 10 years professional experience.
3.What types of machine do you have?
Commonly are paper bag machine V shape bottom or square bottom ,flexo printing machine,slitting machines according to clients'needs.
4.Where is your factory located? how can l visit there?
Our factory is located in ruian city.zhejiang province china.our local airport is Wenzhou Longwan Airportthe nearest international airport is shanghai Pudong Airport about 40 minutes by plane from shanghai (4 hours by train)
5.Can i get some samples? how can l get it?
Yes,we can send you some free samples, but you need to bear the courier cost by DHL, TNT etc.
sincerely welcome all clients to visit us!
We are manufacturer, we have our own worker and factory.
2.How long has your factory been in this field?
In China, As one of the earliest manufacturers in paper bag machine, we have more than 10 years professional experience.
3.What types of machine do you have?
Commonly are paper bag machine V shape bottom or square bottom ,flexo printing machine,slitting machines according to clients'needs.
4.Where is your factory located? how can l visit there?
Our factory is located in ruian city.zhejiang province china.our local airport is Wenzhou Longwan Airportthe nearest international airport is shanghai Pudong Airport about 40 minutes by plane from shanghai (4 hours by train)
5.Can i get some samples? how can l get it?
Yes,we can send you some free samples, but you need to bear the courier cost by DHL, TNT etc.
sincerely welcome all clients to visit us!
