Месяц | Минимальная цена | Макс. стоимость |
---|---|---|
Sep-15-2025 | 13090.77 $* | 13745.33 $* |
Aug-15-2025 | 12980.40 $* | 13629.18 $* |
Jul-15-2025 | 10890.61 $* | 11435.26 $* |
Jun-15-2025 | 12760.95 $* | 13398.98 $* |
May-15-2025 | 11110.24 $* | 11666.57 $* |
Apr-15-2025 | 12540.1 $* | 13167.48 $* |
Mar-15-2025 | 12430.83 $* | 13052.74 $* |
Feb-15-2025 | 12320.81 $* | 12936.12 $* |
Jan-15-2025 | 12210.84 $* | 12821.13 $* |
MAIN DESCRIPTION | value | |
Model | ST5250GYYC | |
Overall Dimension | 11990mm*2495mm*3370mm(L*W*H) | |
Payload | 15ton | |
Dead Weight | 14250kg | |
Front Overhang | 1500mm | |
Rear Overhang | 3315mm | |
Wheelbase | 5825mm+1350mm | |
CHASSIS | 40T | |
Chassis Brand& Model | SINOTRUK HOWO ZZ1257M5841W | |
Axle Number | 3 axles, driving type 6x4 | |
Engine | SINOTRUK WD615.47, 371hp, Euro II emission standard, 4-stroke direct injection diesel engine, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, displacement 9.726L | |
Gear Box | HW197109, No. of speeds: 10 forward & 2 reverse | |
Traversing Mechanism | German ZF8118, turning system pressure 18MPa | |
Clutch | GF430J, Single-plate dry clutch | |
Rear Axle | HC16 tandem axle, rated load 2x16ton, ratio 4.8 | |
Wheels and tires | Rim 8.5-20; tire 12.00-R0, 10 units, with one spare wheel | |
Brakes | Service brake: Dual circuit pneumatic brake; Parking brake: Spring energy, compressed air operating on rear wheels; Auxiliary brake: Engine exhaust brake | |
TANK BODY | ||
Tank Volume | 16.5cbm | |
Tank Dimension | Length 8500mm, Diameter 1800 mm *1470mm (Ellipsoid) | |
Steel thickness | 5mm | |
Accessory | 2 discharge pipes, length 5m |
