Product Description
Specification | Parameter | ||||||
Product Name | RF Band Pass Filter | ||||||
Article Number | UIYBPF5030A1556T1577SF | ||||||
Pass Band | 1556-1577MHz | ||||||
Insertion Loss | <1.0dB | ||||||
Ripple | <0.5 | ||||||
VSWR | <1.4 | ||||||
Rejection | 30dB@DC~1000MHz, 30dB@1625~1660MHz | ||||||
Power | 10W | ||||||
Connector Type | SMA-Female / N-Female | ||||||
Temperature | -55~+85 celsius degree | ||||||
Dimension | 50*30*30mm | ||||||
Warranty | 1 Year | ||||||
Bandpass Filter is a device that allows waves of a specific frequency band to pass through and shields other frequency bands at the same time.
Custom Design
Bandpass Filter Applications.
Aviation and Navigation
Public Address System
Radio Set
Meteorological Monitoring
Biomedical Instrumentation
Optical Communication Technology
Wireless Infrastructure
Microwave Subsystems
4G LTE 5G NR Mobile Communciations
UIY RF Bandpass Filter Custom Design available:
•Band Pass Frequency from DC to 20GHz.
•Connector Type optional 4.3-10 mini DIN, 7/16 DIN, BNC, MCX, SMA and N with female, jack, male, male to female and plug genders.
•Power Offered 2 Watts, 5 Watts, 10Watts, 20Watts, 50 Watts, 75 Watts, 100 Watts, 300Watts.
UIY Inc. provide low insertion loss, high isolation, high power handling on RF Module. Exceptional customer service and technical support are on hand to support our customers.
Due to the diversity of specifications, it is impossible to show all products.
In order to save your valuable time in selecting products, please advise the Frequency, Power, Connector Type, Dimension, or any additional support, please contact our sales directly!
We will provide solutions for you.
Why Choose Us?
Procurement Process
Packing & Delivery
Company Profile
FAQ
1. Question: when can I get the price?
We usually quote within 24 hours after confirming the detailed requirements. If the situation is similar, we can quote
immediately.
2. Question: what is the minimum order quantity?
Minimum order 1 piece.
3. Question: when will the goods be delivered?
The delivery time is usually about 7 - 14 days after ordering.
4. Question: do you only have this product?
No, we can do other products, just need you to give the specific requirements of products and data or templates.
5. Question: what is the quality and quantity of your products?
We have international common materials and different material products, and you can choose according to your needs.
6. Question: why do you choose us?
We focus on Manufacturer RF Microwave Components & Export for 20 years, so we have the advantage of technology and quality, as well as pretty competitive price.
We usually quote within 24 hours after confirming the detailed requirements. If the situation is similar, we can quote
immediately.
2. Question: what is the minimum order quantity?
Minimum order 1 piece.
3. Question: when will the goods be delivered?
The delivery time is usually about 7 - 14 days after ordering.
4. Question: do you only have this product?
No, we can do other products, just need you to give the specific requirements of products and data or templates.
5. Question: what is the quality and quantity of your products?
We have international common materials and different material products, and you can choose according to your needs.
6. Question: why do you choose us?
We focus on Manufacturer RF Microwave Components & Export for 20 years, so we have the advantage of technology and quality, as well as pretty competitive price.
The products are in full compliance with RoHS, ISO9001 and ISO14001 international standard, with high-precision testing equipment and QC team, and we have established a strict quality control system. We are committed to providing our customers with high-quality products for a long time.
Contact information
Contact Supplier : Mr. Sheppard Xue
E-mail : 832@uiy.com
Mob / WhatsApp / Skype : +86 13902992351
Tel : +86 755 83748888-832
Fax : +86 755 25999959
Add : No. 8, lane 1, Xintun East Zone, Longgang District, Shenzhen 518172, China
Web: www.uiy.com
