Volford VF704 модель кондиционера кабины сельское хозяйство тракторы с 8 + и 12 трансмиссией Произведено в провинции
- Категория: Tractors >>>
- Поставщик: Beijing,Taishan,Guotai,Import,Export,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.80 $* | 0.54 $* |
| Aug-18-2025 | 0.44 $* | 0.50 $* |
| Jul-18-2025 | 0.21 $* | 0.94 $* |
| Jun-18-2025 | 0.26 $* | 0.16 $* |
| May-18-2025 | 0.21 $* | 0.68 $* |
| Apr-18-2025 | 0.47 $* | 0.35 $* |
| Mar-18-2025 | 0.55 $* | 0.65 $* |
| Feb-18-2025 | 0.43 $* | 0.35 $* |
| Jan-18-2025 | 0.23 $* | 0.14 $* |
Характеристики
Volford VF704 model air conditioner cabin farming tractors with 8+8 and 12+12 shuttle shift made in Shandong province
| 70HP Tractor Specs | |||
Model | VF704 | |||
Machine Parameters | Type | 4×4 | ||
Rated Traction( KN) | 16.5 | |||
PTO Max Power (KW) | 43.8 | |||
Dimensions(mm) | 3560×1650×2350 | |||
Wheelbase(mm) | 1965 | |||
Track(mm) | Front Wheel(mm) | 1150 | ||
Rear Wheel(mm) | 1200-1360 | |||
Ground Clearance(mm) | Minimum Ground Clearance(mm) | 330 | ||
Mini Turning Radius | Differential Lock(m) | 2.85±0.20 | ||
No Differential Lock(m) | 3.15±0.30 | |||
Weight(kgs) | 2020 | |||
Gearbox | 8F+2R/8F+8R/12F+12R | |||
Steering System | hydraulic steering | |||
Drive Train | Clutch | Dual stage clutch | ||
Working Equipment | Maximum Lifting Force(KN) | ≥10 | ||
Suspension Mechanism | Three-point suspension type I | |||
PTO Shaft | PTO Speed(r/min) | 540/760(option: 540/1000) | ||
Tire | Front Wheel Specifications | 6.5-16/7.5-16/7.5-20/8.3-24 | ||
Rear Wheel Specifications | 11.2-24/12.4-24/12.4-28/14.9-28 | |||
Engine | Type | Inline, 4 stroke, Water cooled | ||
Cylinder | 4 | |||
Optional | Cabin | AC/Heater | ||
Roll bar | ||||
Canopy | ||||
Perfusion Volume | Radiater(L) | 10 | ||
Fuel tank(L) | 29 | |||
Engine oil pan(L) | 5 | |||
Driveline oil (L) | 20 | |||
Lifter(L) | 9.5 | |||
This parameter table is for reference only, everything is based on actual products | ||||
About Us |
Beijing Taishan Guotai Import Export Co., Ltd. is devoting to developing and produce farm wheel tractors from 25hp to 240hp. We are devoted to provide the most suitable tractors and farm equipment according to customers demand. Our company has invested in the construction of Shandong Volford Machinery Co.,Ltd. It was set up in 2015, whic cover about 100,000m2, 10 producing plants, 6 producing lines; the total employee is around 500 people. We have the perfect quality control system to ensure the top quality productions: Professional laboratory, complete test equipment, excellent technical team, including senior engineer 5, and technician 12, strict quality control process.
At present, we mainly make TY series, TE series, TN series, TB series, TD series, TF series, TC series chassis and gearshift wheel tractors. Full series have entered into mass production stage. Market and agents feedback very nice.
We have exported to the countries all over the world, such as Europe, Oceania, East Asia, Southeast Asia, and Africa and so on. We warmly welcome you to visit our factory, and all your comment and advice is highly appreciated.
