Хит продаж, высокопрочный насос для бетонных насосов
US $4800-$5300
Заводская поставка портативный Бетоносмесительный барабан с дизельным двигателем монтажный насос для бетоносмесителей и
- Категория: Concrete Pumps >>>
- Поставщик: Titeco,Industry,Technology,Inc.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.67 $* | 0.81 $* |
| Aug-19-2025 | 0.12 $* | 0.77 $* |
| Jul-19-2025 | 0.11 $* | 0.51 $* |
| Jun-19-2025 | 0.84 $* | 0.14 $* |
| May-19-2025 | 0.42 $* | 0.81 $* |
| Apr-19-2025 | 0.40 $* | 0.98 $* |
| Mar-19-2025 | 0.2 $* | 0.46 $* |
| Feb-19-2025 | 0.72 $* | 0.11 $* |
| Jan-19-2025 | 0.51 $* | 0.91 $* |
Характеристики
Products Description
Model | HBTS-30-10-85R | |||
Max. Theoretical Concrete Output (m3/h) | m3/h | 30 | ||
Max. Concrete pumping Pressure (MPa) | MPa | 10 | ||
Distribution valve | S value | |||
Max. Theoretical Conveying Distance(Horizontal/Vertical) | m | 300/150 | ||
Max.aggregate size | mm | 30 | ||
Concrete slump | mm | 100~200 | ||
Conveying pipe diameter | mm | ø125 | ||
Concrete cylinder bore/stroke | mm | ø180/1000 | ||
Working pressure of pumping hydraulic system | Mpa | 30 | ||
Hopper mixing system hydraulic system working pressure | Mpa | 14 | ||
Hydraulic tank capacity | L | 280 | ||
Noise sound power level | dB(A) | <116 | ||
Total Weight | kg | 5000 | ||
Engine | Model | - | YC04J22T-115 | |
Speed | r/min | 2400 | ||
Power | kw | 85 | ||
Cleaning | High pressure water washing | |||
Dimension | mm | 5800*2150*2600 | ||
Introduction:
During the typical concrete pour, our crawler/trailer type concrete pumps help to place the concrete as close as possible to its final destination—not only to save hauling time and boost productivity, but also to avoid overhandling the concrete. The work of the concrete pumps is an efficient, reliable and economical means of placing concrete, and sometimes the only way of getting concrete into certain locations. All our different models of concrete pumps(diesel or electric powered) provide economic solutions for long-distance and high concrete conveyance via concrete lines or concrete distribution systems.
During the typical concrete pour, our crawler/trailer type concrete pumps help to place the concrete as close as possible to its final destination—not only to save hauling time and boost productivity, but also to avoid overhandling the concrete. The work of the concrete pumps is an efficient, reliable and economical means of placing concrete, and sometimes the only way of getting concrete into certain locations. All our different models of concrete pumps(diesel or electric powered) provide economic solutions for long-distance and high concrete conveyance via concrete lines or concrete distribution systems.
Features:
*High pressure and high performance of diesel-powered engine with a vertical reach from 100 m to 300 m and a horizontal reach about 1,000 m.
*Specially designed with rotary current motor for work in tunnels and emission-free construction site requirements.
*Optimized sealing of S-Valve due to automatic ring.
*High quality wear resistant components.
*All moving parts are highly wear-resistant and are easy to replace.
*All components are largely dimensioned for powerful pump operation.
*Specially formed discharge hopper for optimum concrete flow.
*Powerful and smooth-running pump unit.
*High pressure and high performance of diesel-powered engine with a vertical reach from 100 m to 300 m and a horizontal reach about 1,000 m.
*Specially designed with rotary current motor for work in tunnels and emission-free construction site requirements.
*Optimized sealing of S-Valve due to automatic ring.
*High quality wear resistant components.
*All moving parts are highly wear-resistant and are easy to replace.
*All components are largely dimensioned for powerful pump operation.
*Specially formed discharge hopper for optimum concrete flow.
*Powerful and smooth-running pump unit.
Company Profile
TITECO is a global producer of construction equipment and vehicles, which is specialist in road building, repair and maintenance machinery equipment and vehicles. We offer our customers technologically first-class quality products, creative design services and sound service for optimum, economic production processes. With over 20 years experience in concrete & asphalt road building and maintenance, TITECO's applied technology service will help you to improve your performance. All our products are synonymous of power and stability, always provide the innovative solutions for complex issues.
Our Advantages
1. More than 20 years of cutting edge innovation and expertise help us to provide you all the best solutions of your projects.
2. With all kinds of our products commissioned for the concrete and asphalt industry projects,we believed that we know the cares and concerns of our customers well.
3. TITECO manufactures all equipment in our own factory under the strick quaility control system, makes the equipment much more reliable.
Production Process
Partner
Product Packaging
FAQ
Could you guarantee the quality of your products?
Quality control system certified with ISO 9001, All equipments under the strick quaility control system.
Quality control system certified with ISO 9001, All equipments under the strick quaility control system.
What is the MOQ?
In order to help our clients have a good understanding of the product, we can start order from 1 Unit.
In order to help our clients have a good understanding of the product, we can start order from 1 Unit.
I cannot find the suitable model, can I ask for a special model I need?
Sure. Kindly please advising the detail specification you need, we will make it according to your request.
Do you offer guarantee for the products?
Yes, we offer 1-years warranty for all equipment dated from the delivery.
Yes, we offer 1-years warranty for all equipment dated from the delivery.
What are your payment terms?
30% TT as deposit,70% TT before Shipment.
30% TT as deposit,70% TT before Shipment.
What about the lead-time?
Normally 15-30 working days after receiving the down payment.
Normally 15-30 working days after receiving the down payment.
Is it all right to make customer's own brand name?
We can be your OEM manufacture with your authorization of brand.
We can be your OEM manufacture with your authorization of brand.
