Высококачественные инструменты для гидравлического гибочного станка пресс-тормоза
- Категория: Other Bending Machines >>>
- Поставщик: Maanshan,Hengkun,Machinery,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 357.15 $* | 375.65 $* |
| Aug-18-2025 | 354.16 $* | 372.51 $* |
| Jul-18-2025 | 297.53 $* | 312.95 $* |
| Jun-18-2025 | 348.78 $* | 365.18 $* |
| May-18-2025 | 303.51 $* | 318.37 $* |
| Apr-18-2025 | 342.2 $* | 359.69 $* |
| Mar-18-2025 | 339.25 $* | 356.39 $* |
| Feb-18-2025 | 336.56 $* | 353.61 $* |
| Jan-18-2025 | 333.69 $* | 350.30 $* |
Характеристики
Products Description
It is mainly suitable for the material selection of bending machine, such as thin, medium, thick plate, cold and hot transverse shear, longitudinal cutting, rolling, hot rolling, etc.: t8a, t10a, 55sicr, and 42crmo quenching hardness (hrc): the product features of the following 55 °: the concentricity is good, the precision is high, the whole quenching is high, the surface finish is high, the wear resistance and the tolerance are high: Up to 0.02, up to the import ammada standard product price: according to the different mould requirements, and the size and the mould type, the precision bending machine mould upper die is:90 °,88 °,26°,35 °,45 °,60 ° and 30 ° lower mould:88 °,90 °,35 °,60 °,30 °,45 °; CNC bending tool segment, general segment specification is as follows: mold segment 1 numerical control bending upper mold:100 (left),10,15,20,40,50,200,300,100 (right) = 835 mm numerical control bending lower mold:10,15,20,40,50,100,200,400 = 835 mm mold segment 2 numerical control bending upper mold:100 (left),10,15,20,40,50,165,300,100 (right) = 800 mm
Common Bending Machine Model | Shape Size of Upper Abrasive Tool mm | Shape Dimension of Lower Die mm |
40T/2000 | 2000x70x18 | 2000x55x55 |
40T/2000 | 2000x80x18 | 2000x75x75 |
40T/2000 | 2000x90x30 | 2000x55x55 |
40T/2000 | 2000x150x26 | 2000x55x50 |
63T/2500 | 2000x85x28 | 2500x70x70 |
63T/2500 | 2500x150x25 | 2500x65x65 |
63T/2500 | 2500x85x28 | 2500x55x55 |
63T/2500 | 2500x100x20.5 | 2500x70x70 |
80T/3200 | 3200x80x18 | 3200x95x95 |
100T/3200 | 320x150x26 | 3200x95x95 |
100T/3200 | 3250x86x28 | 3250x75x75 |
100T/3200 | 3200x72x30 | 3200x100x100 |
100T/3200 | 3250x80x25 | 3250x95x95 |
100T/3200 | 3200x85x25 | 3200x75x75 |
100T/3200 | 3200x80x25 | 3200x95x95 |
160T/3200 | 3200x90x56 | 3200x110x110 |
160T/4000 | 4000x80x25 | 4000x110x110 |
160T/4000 | 4000x90x30 | 4000x110x110 |
160T/4000 | 4000x134x34 | 4000x120x120 |
