Лидер продаж передвижная Коммерческая полностью автоматическая моечная машина 8
- Категория: Car Washer >>>
- Поставщик: Wuxi,Yazhou,Precision,Machine,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 27572.46 $* | 28951.20 $* |
| Aug-19-2025 | 27341.29 $* | 28708.92 $* |
| Jul-19-2025 | 22938.82 $* | 24085.67 $* |
| Jun-19-2025 | 26877.19 $* | 28221.45 $* |
| May-19-2025 | 23402.23 $* | 24572.93 $* |
| Apr-19-2025 | 26414.38 $* | 27735.82 $* |
| Mar-19-2025 | 26182.16 $* | 27491.29 $* |
| Feb-19-2025 | 25950.90 $* | 27248.95 $* |
| Jan-19-2025 | 25719.19 $* | 27005.19 $* |
Характеристики
Model | RV3200 |
Standard Equipment | Horizontal brush *1 pc Vertical Brush*2 Rock Brush*2 Foaming System*1 Waxing System*1 |
Dimension | 3450mm * 2800m * 1900mm (W * H * L） |
Max. Washing size | 2300 mm* 2100 mm* 5300 mm (W * H * L) |
Operation area | 4800mm * 2900mm * 9500mm （W * H * L） |
Equipment Room（S） | ＞4m² |
Total Weight | ＜2000kg |
Total Power Consumption | ~10kw |
Water Requirement | Pipe DN25 Flow＞150L/min |
Air Compressor Requirement | ≥0.7MPa，100L |
Vehicle Size | 2300mm * 1960mm * 5300mm (W * H * L） |
Maximum Power | ~8Kw |
Electricity Consumption | 0.25Kw / car |
Water Consumption | 100L~120L / car |
Minimum Washing Time | 1:30 |
Rollover Main Part Brand | ||||||
No. | Name | Brand | Origin | |||
1 | HMI | Weintek/Flexem | Taiwan/Shanghai | |||
2 | button | Schneider | France | |||
3 | Contactor | Schneider | France | |||
4 | Relay | Schneider,Omron | France/Japan | |||
5 | Protector | Schneider | France | |||
6 | Switch | Shilin | Taiwan | |||
7 | VFD(Inverter) | Shilin | Taiwan | |||
8 | PLC | Mitsubishi | Japan | |||
9 | Photosensor | Pepperl+Fuchs/MD | Germany/Italy | |||
10 | Proximity Sensor | Pepperl+Fuchs | Germany | |||
11 | Solenoid valve | Airtac | Taiwan | |||
12 | Dosing Pump | ProMinent/Ecolab | Germany | |||
13 | Reducer | Siti/ASIA WASH | Italy/Taiwan | |||
14 | Motor | SEW/ASIA WASH | Germany/Taiwan | |||
O:What are the different models of car washing machines available for purchase?
A:Tunnels and Roll-overs (or gantry) Touchless (with high-pressure water) are the most common for regular commercial use.
Q:What is the delivery time?
A:15-60 days after receiving the order confirmation. Generally, it depends on the model.
Q:How to install the machine?
A:We provide an installation manual and operation manual. Online service is open at any time. We will also provide the foundation drawings for the civil work if necessary. On-site installation is limited during the pandemic.
Q:What is the daily maintenance procedure?
A:Please follow the operational manual.
Q:How to solve errors and malfunctions?
A:Please follow the operational manual. It is recommended to connect the Internet to the machine, which allows our Engineer to debug remotely.
Q:What is the warranty?
A:1-year warranty for the machine in general. The POM conveyor belt is guaranteed for 2 years or 300 thousand washes. We suggest preparing common spare parts along with the machine.
Q:How much will the maintenance cost?
A:It is estimated to be 5% of the price in the 2nd year, 6% of the price in the 3rd year, 8% of the price in the 4th year, and under 10% of the price starting from the 5th year under the condition that the maintenance guidance is followed carefully and the machine operates every day non-stop for 8 hours.
Q:Can I get repair parts in the future?
A:Yes. We have inventory for common parts regularly. Special parts or old designs will have a different cost and production time.
Q:How long will the foundation civil work take?
A:7-10 days in general.
Q:What is the power consumption per car washing?
A:Please refer to the catalog. The blower is the most power-consuming part of the machine.
Q:What is the water consumption per car washing?
A:Please refer to the product specification. With proper water reclaim system, up to 70% of the water can be recycled to the system.
