Грузовик с воздушной платформой Marilyn DONGFENG DKL
US $12000-$29900
Сделано в Китае XGS72J от 24 мес. до верхней части конфигурации телескопическая самоходная гидравлический воздушная Рабочая платформа по лучшей
- Категория: High-altitude Operation Trucks >>>
- Поставщик: Sinomada,Heavy,Industry,(Changsha),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 105777.87 $* | 111066.95 $* |
| Aug-16-2025 | 104888.28 $* | 110132.53 $* |
| Jul-16-2025 | 87999.39 $* | 92399.52 $* |
| Jun-16-2025 | 103110.38 $* | 108266.45 $* |
| May-16-2025 | 89777.6 $* | 94266.57 $* |
| Apr-16-2025 | 101332.49 $* | 106399.5 $* |
| Mar-16-2025 | 100443.32 $* | 105465.64 $* |
| Feb-16-2025 | 99555.20 $* | 104533.99 $* |
| Jan-16-2025 | 98666.94 $* | 103599.44 $* |
Характеристики
China Made XGS72J 24M Top Configuration Telescopic Self Propelled Hydraulic Boom Aerial Working Platform Best Price
Product Description
Telescopic work platform XGS72J straight arm and self-propelled platform lift highlights with outstanding performance, efficiency, dynamics and easy operation.
Telescopic work platform XGS72J is leading in the industry with maximum carrying capacity of 340kg, high operation height and amplitude, suit for construction of large load and wide operation area.
Advantages and features:
1. Realize the dynamic adjustment of vehicle center of gravity, making the complete vehicle more stable.
2. Telescopic work platform XGS72J is excellent in drive and adaptability to road.
3. Making its work performance at leading edge.
4. Improves safety of extending mechanism and extends service life of steel rope.
5. Implementing the auto leveling, the dynamic monitoring and the fault warning.
- Specification
Item | Unit | Parameter |
Overall length of complete machine | mm | 10150 |
Overall width of complete machine | mm | 2490 |
Overall height | mm | 2800 |
Wheelbase | mm | 2500 |
Maximum working height | m | 24 |
Maximum platform height | m | 22 |
Maximum working range | m | 18.3 |
Maximum carrying weight | kg | 230/340 |
Luffing range of boom | ° | -5 ~ +75 |
Slewing angle of turntable | ° | 360 |
Maximum rearward slewing | mm | 1550 |
Dimension of platform | mm | 2400×900 |
Slewing angle of platform | ° | 160 |
Overall weight | kg | 12500 |
Maximum traveling speed | km/h | 6 |
Minimum turning radius | m | 6 |
Minimum ground clearance | mm | 230 |
Maximum gradeability | % | 45 |
Specification of tire | - | 355/55D625 |
Engine model | - | Deeutz TD 2.9 L4 |
Engine rated power | kW/(r/min) | 55.4/(2600) |
- Product Pictures
- Get More
Contact Elva for more information
TEL/WhatsApp: +86 18974121205
Wechat: 18974121205
E-mail: Elva@ sinomada.com
