 Best Quality and Price TSP thermal stable polycrystalline

TSP diamond is made from binding agent presenting inert to the diamond and diamond particles under high temperature and high pressure conditions. it has extremely high heat resistance and very high thermal stability.



Application:

TSP diamond (thermal stable pollycrystalline) is widely applied in the manufacture of petroleum and geological drill bit , natural diamond polishing etc



We use different formulations and processes to produce drill bit polycrystalline and gauge protection polycrystalline under high temperature and high pressure. It has a very high abrasive ratio and the use-cost is very low compared with natural metal and stones. It is ideal materials for geological drill bits and has been adopted by major oilfields and drill bit manufacturers at home and abroad.



Type:

1, nickel-plated type

2, natrual diamond polishing type

3, thermal stable diamond type



Specifications:

Shape	Model	Size
cylinder	R2040	2.0*4.0mm
	R6333	6.3*6.3mm
	R1050	10*5.0mm
Square	L151515	1.5*1.5*1.5mm
	L151530	1.5*1.5*3.0mm
	L151550	1.5*1.5*5.0mm
	L303050	3.0*3.0*5.0mm
	L404040	4.0*4.0*4.0mm
	L404060	4.0*4.0*6.0mm
	L505050	5.0*5.0*5.0mm
Triangle	T404026	4.0*4.0*2.6mm
	T626243	6.2*6.2*4.3mm
Special-shaped	A100303015	10*3.0*3.0*R1.5mm
	A1001003015	10*10*3.0*R1.5mm
	A100505025	10*5.0*5.0*R2.5mm



Service:

customizing size and shape
