Din рейка крепление 3-фазный цифровой ac Электрический счетчик
- Категория: Energy Meters >>>
- Поставщик: Acrel,Electric,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.67 $* | 0.49 $* |
| Aug-18-2025 | 0.84 $* | 0.16 $* |
| Jul-18-2025 | 0.53 $* | 0.65 $* |
| Jun-18-2025 | 0.86 $* | 0.53 $* |
| May-18-2025 | 0.5 $* | 0.78 $* |
| Apr-18-2025 | 0.13 $* | 0.46 $* |
| Mar-18-2025 | 0.14 $* | 0.78 $* |
| Feb-18-2025 | 0.83 $* | 0.38 $* |
| Jan-18-2025 | 0.84 $* | 0.29 $* |
Характеристики
Product Discription
Voltage | Reference voltage | AC 220V |
Reference frequency | 45-65 Hz | |
Consumption | <10VA( Single phase) | |
Current | Maximum | 60A |
Starting current | 0.004 Ib | |
Consumption | <4VA(Maximum current) | |
Measurement performance | Accuracy of active kWH | Class 1 |
Standards complicant | IEC 62053-21:2003 | |
Pulse | Pulse width | 80+20 ms |
Pulse constant | 3200 imp/kWH | |
Communication | Interface | RS485 |
Protocol | Modbus-RTU | |
Outling | L*W*H(mm) | 18*88*70 |
Environment | Temperature | Operating:-25℃~55℃；Storage:-40℃~70℃ |
Humidity | ≦95% (No condensation) | |
Altitude | <2000m | |
Reference voltage | AC 220V | |
Reference frequency | 45-65 Hz | |
Consumption | <10VA( Single phase) | |
Maximum | 60A | |
Starting current | 0.004 Ib | |
Consumption | <4VA(Maximum current) | |
Accuracy of active kWH | Class 1 | |
Standards complicant | IEC 62053-21:2003 | |
Pulse width | 80+20 ms | |
Pulse constant | 3200 imp/kWH | |
Interface | RS485 | |
Protocol | Modbus-RTU | |
L*W*H(mm) | 18*88*70 | |
Temperature | Operating:-25℃~55℃；Storage:-40℃~70℃ | |
Humidity | ≦95% (No condensation) | |
Altitude | <2000m |
Company Profile
Certifications
Exhibition
Packaging and shipping
FAQ
Q:Where is your company located?
A:Our headquarter is in Shanghai, our factory locates in Jiangyin,Jiangsu Province,China.It takes about 1 hour by car from
Shanghai Hongqiao International Airport to our factory. As it is low labor cost here in Jiangsu,we can offer a better price with
high quality.
Q:What’s your lead time?
A:Sample time 1-3days,mass production 10~20days for order more than 500pcs
Q:Payment terms?
A:Usually,TT,credit card,western union,in cash and so on.You can also choose to pay 30% as deposit and the balance before shipment
or against copy of B/L if the order is large.
Q:Can other logo be put on your products(OEM)?
A:Yes,but MOQ for OEM will be at least 100pcs.We also need you provide logo Ai Format or EPS.
For more questions, please mail me to elena@acrel.cn or call me +86 18702109693
A:Our headquarter is in Shanghai, our factory locates in Jiangyin,Jiangsu Province,China.It takes about 1 hour by car from
Shanghai Hongqiao International Airport to our factory. As it is low labor cost here in Jiangsu,we can offer a better price with
high quality.
Q:What’s your lead time?
A:Sample time 1-3days,mass production 10~20days for order more than 500pcs
Q:Payment terms?
A:Usually,TT,credit card,western union,in cash and so on.You can also choose to pay 30% as deposit and the balance before shipment
or against copy of B/L if the order is large.
Q:Can other logo be put on your products(OEM)?
A:Yes,but MOQ for OEM will be at least 100pcs.We also need you provide logo Ai Format or EPS.
For more questions, please mail me to elena@acrel.cn or call me +86 18702109693
