Замок для врезной двери с особым дизайном unit
- Категория: Locks >>>
- Поставщик: China,Arts,And,Crafts,Nanjing,I/E,Corp.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 5.62 $* | 5.0 $* |
| Aug-20-2025 | 5.50 $* | 5.53 $* |
| Jul-20-2025 | 4.70 $* | 4.1 $* |
| Jun-20-2025 | 5.39 $* | 5.76 $* |
| May-20-2025 | 4.59 $* | 4.60 $* |
| Apr-20-2025 | 5.63 $* | 5.13 $* |
| Mar-20-2025 | 5.72 $* | 5.7 $* |
| Feb-20-2025 | 4.48 $* | 4.44 $* |
| Jan-20-2025 | 4.53 $* | 4.94 $* |
Характеристики
Specifications and Features
–ML108502 passage mortise lock latch has modular case across functions for rapid door prepping, and installation
–85mm centers, backset in 40/45/50/60mm
–8mm follower with spindle gripping function
–Reversible latch bolt in solid stainless steel
–Suitable for sprung and most un-sprung lever furniture
–Stainless steel faceplate and strike in square and radius version (radius version improves door prep efficiency with machine
routing)
–Compatible with bolt through furniture and escutcheons of 38mm centers
–85mm centers, backset in 40/45/50/60mm
–8mm follower with spindle gripping function
–Reversible latch bolt in solid stainless steel
–Suitable for sprung and most un-sprung lever furniture
–Stainless steel faceplate and strike in square and radius version (radius version improves door prep efficiency with machine
routing)
–Compatible with bolt through furniture and escutcheons of 38mm centers
Application
UNITY ML1085 Series Mortice Lock is designed for high frequency usage applications such as public access buildings where deliberate abuse likely takes place. | ||||||||
UNITY ML108502 passage mortise lock latch is suitable for latched doors remaining unlocked at all times. | ||||||||
Test and Standards
Successfully type-tested for conformity to all of requirement of EN12209: 2003
Successfully passed and exceeded 240-minutes fire test of metal fire door assemblies to EN1634-1: 2014
CE Declaration of Conformity available upon request
Meets the dimensional recommendations of BS8300 and Approved Document "M"
UNITY ML1072 series locks are approved by Certifire.* Certifire No. CF5333
All EN/CE/Certifire tests performed independently and certified by Exova/ Warrington Fire/Warrington APT. Test report/ certificate are available upon request.
Forend and Strike Finishes
Other Finish Available Upon Request:
– Polished Stainless Steel (US32/629)
– Satin PVD Titanium
– Bright PVD Titanium
Lever Options
Suitable with any UNITY lever design
* Please refer to UNITY Lever Handle catalogue for more detail on Lever and Trim options
Function
Sashlock/Entry
Suitable for latched doors requiring deadbolt locking security.
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
China Arts And Crafts Nanjing I/E Corp. | ||
Quality assurance | Trade assurance supplier | |
Export experience | More than 20 years experience | |
Sample | Available | |
OEM | Accept | |
Main product | Door Lock,Door Handle,Door Hinge,Door Hardware | |
Q: Are your company a factory or trading company?
A: UNITY started from a trade company, but now we have two factory plants toserve you. As a manufacturer, we have more than 20 year's experiences and are confident to offer you with optimal manufacturin solution.
Q: What kinds of certificates do you have?
A: UNITY have CE and UL certificate, all our product design follows up the international standard, such as the EN/CE, UL, ANSI standard.
Q: Do you accept OEM or ODM?
A: Yes, UNITY is professional in OEM and ODM with more than 20 year's experiences. And UNITY has set up long-term cooperation with many famous brands home and abroad.
Q: How about your quality system?
A: As a factory, UNITY has been certified by ISO9001 and ISO14001 to well control our production and service quality, all steps under control are strictly processed according to these authoritative systems and standards.
Q: Can you send me a sample before placing an order? Is it free?
A: Yes, of course. UNITY will translate all your requirement into real products and then send you samples for your confirmation.
Sample is free, you just need to pay for the express cost.
Q: How many days do you need for prepare sample?
A: Usually 2-5 days.
Q: What’s stainless steel grade you are working now?
A: We are working mostly in SUS304 and SUS316, some items can be SUS201 aswell.Any more information of further questions, please just feel free to contact us.
Q: What kinds of certificates do you have?
A: UNITY have CE and UL certificate, all our product design follows up the international standard, such as the EN/CE, UL, ANSI standard.
Q: Do you accept OEM or ODM?
A: Yes, UNITY is professional in OEM and ODM with more than 20 year's experiences. And UNITY has set up long-term cooperation with many famous brands home and abroad.
Q: How about your quality system?
A: As a factory, UNITY has been certified by ISO9001 and ISO14001 to well control our production and service quality, all steps under control are strictly processed according to these authoritative systems and standards.
Q: Can you send me a sample before placing an order? Is it free?
A: Yes, of course. UNITY will translate all your requirement into real products and then send you samples for your confirmation.
Sample is free, you just need to pay for the express cost.
Q: How many days do you need for prepare sample?
A: Usually 2-5 days.
Q: What’s stainless steel grade you are working now?
A: We are working mostly in SUS304 and SUS316, some items can be SUS201 aswell.Any more information of further questions, please just feel free to contact us.
