Датчик углекислого газа ASAIR ACD10
- Категория: Gas Analyzers >>>
- Поставщик: Guangzhou,Aosong,Electronic,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 12.47 $* | 13.4 $* |
| Aug-19-2025 | 12.20 $* | 13.79 $* |
| Jul-19-2025 | 10.81 $* | 11.64 $* |
| Jun-19-2025 | 12.79 $* | 13.59 $* |
| May-19-2025 | 10.13 $* | 11.76 $* |
| Apr-19-2025 | 11.94 $* | 12.42 $* |
| Mar-19-2025 | 11.18 $* | 12.57 $* |
| Feb-19-2025 | 11.35 $* | 12.67 $* |
| Jan-19-2025 | 11.28 $* | 12.73 $* |
Характеристики
Product Summary
ACD10 uses the principle of non-dispersive infrared (NDIR) to detect the concentration of carbon dioxide in the air. ACD10 has the advantages of good selectivity, no oxygen dependence, and long life; built-in temperature compensation; with digital interface output, easy to use. ACD10 is a high-performance sensor that combines infrared absorption gas detection technology, precise optical circuit design, and high-precision signal detection circuit design.
Parameter | Condition | MIN | TYP | MAX | Unit | ||||
Measurement Range | - | 400 | - | 5000 | ppm | ||||
Preheat Time | - | - | 120 | - | S | ||||
Power Supply | - | 4.75 | 5 | 5.25 | V | ||||
Operating Temperature | - | -10 | - | 50 | ℃ | ||||
Operating Humidity | Noncondensing | 0 | - | 95 | %RH | ||||
Accuracy | ±(50 + 5% reading) | - | ±2 | - | %RH | ||||
Data Refresh Frequency | 1s | - | 8 | - | s | ||||
Output | UART or I2C | - | <0.1 | - | ℃/yr | ||||
Warranty | 12 months | - | <1 | - | %RH/yr | ||||
Note
UART, compatible with 3 and 5 levels. For other communication protocols (I2C or other), please contact us.
