Поддержка ODM сервиса различные дополнительные модули доступные туннельные машины для мойки
- Категория: Car Washer >>>
- Поставщик: Wuxi,Yazhou,Precision,Machine,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 63082.70 $* | 66236.75 $* |
| Aug-19-2025 | 62552.90 $* | 65680.88 $* |
| Jul-19-2025 | 52480.14 $* | 55104.33 $* |
| Jun-19-2025 | 61492.24 $* | 64567.96 $* |
| May-19-2025 | 53540.2 $* | 56217.66 $* |
| Apr-19-2025 | 60431.95 $* | 63453.25 $* |
| Mar-19-2025 | 59901.78 $* | 62896.99 $* |
| Feb-19-2025 | 59371.55 $* | 62340.1 $* |
| Jan-19-2025 | 58841.72 $* | 61783.89 $* |
Характеристики
Model | TN545103/TN545113 |
Standard Equipment | High-pressure washing system (top/side)*1pc Contouring Up/down horizontal brush *1 pc Rock Brushes * 4 pc ( Left*2 & Right*2) Vertical Brushes * 4 pc ( Left*2 & Right*2) Top Blower * 3 pc Side Blower * 2 pc ( Left *1 & Right *1) Contouring Up/down Horizontal Wiper*1pc Foaming system Waxing system |
Dimension | 3700mm*3100mm*21450mm (W*H*L) |
Max. Washing size | 2300 mm* 2100 mm* 5300 mm (W * H * L) |
Operation area | 4100mm * 3100 mm * 23000mm (W*H*L) |
Conveyer Length | 11.74m |
Total power consumption | ~ 47kw |
Power Expense | 0.4 kwh ~0.6 kwh / car |
Water Expense | 100L~150L / car |
Wash speed | 50cars / h |
Tunnel Main Part Brand | ||||||
No. | Name | Brand | Origin | |||
1 | HMI | Weintek/Flexem | Taiwan/Shanghai | |||
2 | button | Schneider | France | |||
3 | Contactor | Schneider | France | |||
4 | Relay | Schneider,Omron | France/Japan | |||
5 | Protector | Schneider | France | |||
6 | Switch | Shilin | Taiwan | |||
7 | VFD(Inverter) | Shilin | Taiwan | |||
8 | PLC | Mitsubishi | Japan | |||
9 | Photosensor | Pepperl+Fuchs/MD | Germany/Italy | |||
10 | Proximity Sensor | Pepperl+Fuchs | Germany | |||
11 | Solenoid valve | Airtac | Taiwan | |||
12 | Dosing Pump | ProMinent/Ecolab | Germany | |||
13 | Reducer | Siti/ASIA WASH | Italy/Taiwan | |||
14 | Motor | SEW/ASIA WASH | Germany/Taiwan | |||
O:What are the different models of car washing machines available for purchase?
A:Tunnels and Roll-overs (or gantry) Touchless (with high-pressure water) are the most common for regular commercial use.
Q:What is the delivery time?
A:15-60 days after receiving the order confirmation. Generally, it depends on the model.
Q:How to install the machine?
A:We provide an installation manual and operation manual. Online service is open at any time. We will also provide the foundation drawings for the civil work if necessary. On-site installation is limited during the pandemic.
Q:What is the daily maintenance procedure?
A:Please follow the operational manual.
Q:How to solve errors and malfunctions?
A:Please follow the operational manual. It is recommended to connect the Internet to the machine, which allows our Engineer to debug remotely.
Q:What is the warranty?
A:1-year warranty for the machine in general. The POM conveyor belt is guaranteed for 2 years or 300 thousand washes. We suggest preparing common spare parts along with the machine.
Q:How much will the maintenance cost?
A:It is estimated to be 5% of the price in the 2nd year, 6% of the price in the 3rd year, 8% of the price in the 4th year, and under 10% of the price starting from the 5th year under the condition that the maintenance guidance is followed carefully and the machine operates every day non-stop for 8 hours.
Q:Can I get repair parts in the future?
A:Yes. We have inventory for common parts regularly. Special parts or old designs will have a different cost and production time.
Q:How long will the foundation civil work take?
A:7-10 days in general.
Q:What is the power consumption per car washing?
A:Please refer to the catalog. The blower is the most power-consuming part of the machine.
Q:What is the water consumption per car washing?
A:Please refer to the product specification. With proper water reclaim system, up to 70% of the water can be recycled to the system.
