Вертикальное Крепление с кнопкой B10K пружинный потенциометр мгновенным
- Категория: Potentiometers >>>
- Поставщик: Chengdu,Cuanstar,Union,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.20 $* | 0.73 $* |
| Aug-20-2025 | 0.2 $* | 0.63 $* |
| Jul-20-2025 | 0.59 $* | 0.70 $* |
| Jun-20-2025 | 0.90 $* | 0.11 $* |
| May-20-2025 | 0.37 $* | 0.52 $* |
| Apr-20-2025 | 0.93 $* | 0.11 $* |
| Mar-20-2025 | 0.10 $* | 0.81 $* |
| Feb-20-2025 | 0.6 $* | 0.28 $* |
| Jan-20-2025 | 0.53 $* | 0.34 $* |
Характеристики
Push vertical mount B10K self return spring potentiometer with momentary switch
vertical mount B10K smooth shaft D shaft potentiometer
can add push switch or rotary switch
9mm single gang linear type single lap digital potentiometer with metal shaft Highest working Voltage:B taper 50V AC other taper 25V AC traveling noise: 100mv Rotational torque:10~200gf.cm Total Rotational angle:300°±10° Rotation stop strength:3Kgf.cm shaft strength:8Kgf max. shaft shaking:0.6×L/20mm p-p max. Resistance tolerance:±20% resistance residue:R≤10KΩ 10Ω;10K<R<250KΩ 20Ω;R≥250K 0.1% max. of total resistance Power:B taper 0.05W other taper 0.025W Insulation resistance:100MΩ min. at 250V DC Voltage resistance:1 minute at 300V |
WELCOME INQUIRY!
