Двухрядный Сферический роликовый подшипник 22226 МБ, сделано в Китае
US $18.00-$20.00
Заводская Прямая цена большой запас качественный Сферический роликовый подшипник CA MB CC W33 22215 22216 22217 22320 22322 22324 22326
- Категория: Spherical Roller Bearing >>>
- Поставщик: Hefei,Rowiss,Bearing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.95 $* | 0.81 $* |
| Aug-19-2025 | 0.7 $* | 0.87 $* |
| Jul-19-2025 | 0.82 $* | 0.93 $* |
| Jun-19-2025 | 0.47 $* | 0.41 $* |
| May-19-2025 | 0.12 $* | 0.30 $* |
| Apr-19-2025 | 0.20 $* | 0.17 $* |
| Mar-19-2025 | 0.78 $* | 0.20 $* |
| Feb-19-2025 | 0.57 $* | 0.51 $* |
| Jan-19-2025 | 0.58 $* | 0.5 $* |
Характеристики
Zero Risk Commitment
1. Quality commitment: All bearings are 100% inspected in the same standard with 12 months warranty when sent out. If quality problems occur, we will compensate according to the actual loss when you submit the third party report to us (such as SGS and Lloyd's, etc).
2. Delivery commitment: All goods will be delivered on time when the order confirmed. If the order will be delayed, the penalty must be executed by 100USD each day up to 5% the order total amount.
3. Service commitment: All emails will be replied within 1 hours during working time, the enquiry and order must be handled within 7 hours (8:30AM - 5:30PM, Monday - Friday). If you have any complaints with our service, please send your email to us, we are at your disposal.
Product Description
Spherical Roller Bearing
ROWISS Spherical roller bearings have two rows of rollers with a common sphere raceway in the outer ring and two inner ring raceways inclined at an angle to the bearing axis. This gives them an attractive combination of design features making them irreplaceable in many demanding applications. They are self-aligning and consequently insensitive to misalignment of the shaft relative to the housing and to shaft deflection or bending.
Materials:
1. Material of ring : GCr15,
2.Material of Cage: Steel, brass, polyamide, nylon
3.Material of Roller: chromium steel
Structure:
Internal Structure and Retainer Material Variation
C: Symmetrical roller, Stamped Steel retainer
CA: Symmetrical roller, one-pice brass cage
CTN1: Symmetrical roller, nylon cage
E: Third generation design. improved stress distribution; offer much longer service life than normal designs
Q: Bronze cage
MB: Symmetrical roller,Two-pice brass cage
EM: Symmetrical roller, Special alloy Integral cage.
External form change:
K: Tapered bore bearing,taper is 1:12
K30: Tapered bore bearing,taper is 1:30
N: A snap ring groove on the outer ring
W33: There are three lubrication groove and three lubrication holes in the outer ring
Clearance:
C0:Norminal clearance,omitted in destination
C2:Less than Norminal clearance
C3:Larger clearance than C0
C4: Larger clearance than C3
Application:
1.Papermaking machinery, deceleration device, railway vehicle axle, rolling mill, roller gearbox
2. Crusher, vibrating screen, printing machinery, woodworking machinery
3.Various industrial reducer
Materials:
1. Material of ring : GCr15,
2.Material of Cage: Steel, brass, polyamide, nylon
3.Material of Roller: chromium steel
Structure:
Internal Structure and Retainer Material Variation
C: Symmetrical roller, Stamped Steel retainer
CA: Symmetrical roller, one-pice brass cage
CTN1: Symmetrical roller, nylon cage
E: Third generation design. improved stress distribution; offer much longer service life than normal designs
Q: Bronze cage
MB: Symmetrical roller,Two-pice brass cage
EM: Symmetrical roller, Special alloy Integral cage.
External form change:
K: Tapered bore bearing,taper is 1:12
K30: Tapered bore bearing,taper is 1:30
N: A snap ring groove on the outer ring
W33: There are three lubrication groove and three lubrication holes in the outer ring
Clearance:
C0:Norminal clearance,omitted in destination
C2:Less than Norminal clearance
C3:Larger clearance than C0
C4: Larger clearance than C3
Application:
1.Papermaking machinery, deceleration device, railway vehicle axle, rolling mill, roller gearbox
2. Crusher, vibrating screen, printing machinery, woodworking machinery
3.Various industrial reducer
Specification
item | value |
Type | Roller |
Structure | Spherical |
Applicable Industries | Manufacturing Plant, Machinery Repair Shops, Construction works , Energy & Mining |
Brand Name | ROWISS or Your Brand |
Model Number | 22215 22216 22217 22320 22322 22324 22326 22330 |
Precision Rating | ABEC1 ABEC3 ABEC5 ABEC7 |
Seals Type | OPEN |
Number of Row | Double row |
Place of Origin | China |
Product name | Spherical Roller Bearing |
Material | Chrome Steel GCR15 |
Cage | Steel Cage.Brass Cage |
Clearance | C0 C2 C3 C4 C5 |
Hardness | HRC58-62 |
Feature | Heavy Loading Duty |
Quality | ISO Standard |
Service | OEM Service.Design Service |
Sample | Avaliable |
Delivery | 1~15days |
Series | Model No | d(mm) | D(mm) | B(mm) | Series | Model No | d(mm) | D(mm) | B(mm) |
21300 series | 21307 | 35 | 72 | 23 | 22200 series | 22205 | 25 | 52 | 18 |
21308 | 40 | 90 | 23 | 22206 | 30 | 62 | 20 | ||
21309 | 45 | 100 | 25 | 22207 | 35 | 72 | 23 | ||
21310 | 50 | 110 | 27 | 22208 | 40 | 80 | 23 | ||
21311 | 55 | 120 | 29 | 22209 | 45 | 85 | 23 | ||
... | ... | ... | .. | ... | ... | ... | ... | ||
23000series | 23020 | 100 | 150 | 37 | 24000 series | 24015 | 75 | 115 | 40 |
23022 | 110 | 170 | 45 | 24018 | 90 | 140 | 50 | ||
23024 | 120 | 180 | 46 | 24020 | 100 | 150 | 50 | ||
23028 | 140 | 210 | 53 | 24024 | 120 | 180 | 60 | ||
23030 | 150 | 225 | 56 | 24026 | 130 | 200 | 69 | ||
... | ... | ... | ... | ... | ... | ... | ... | ||
22300 series | 22307 | 35 | 80 | 31 | 24100 series | 24120 | 100 | 165 | 65 |
22308 | 40 | 90 | 33 | 24122 | 110 | 180 | 69 | ||
22309 | 45 | 100 | 36 | 24124 | 120 | 200 | 80 | ||
22310 | 50 | 110 | 40 | 24126 | 130 | 210 | 80 | ||
22311 | 55 | 120 | 43 | 24128 | 140 | 225 | 85 | ||
... | ... | ... | ... | ... | ... | ... | ... |
