Маленький гидравлический экскаватор мини бытовой евро в дизельный двигатель
- Категория: Excavators >>>
- Поставщик: Titeco,Industry,Technology,Inc.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.90 $* | 0.33 $* |
| Aug-19-2025 | 0.33 $* | 0.11 $* |
| Jul-19-2025 | 0.69 $* | 0.10 $* |
| Jun-19-2025 | 0.69 $* | 0.50 $* |
| May-19-2025 | 0.98 $* | 0.64 $* |
| Apr-19-2025 | 0.8 $* | 0.9 $* |
| Mar-19-2025 | 0.95 $* | 0.16 $* |
| Feb-19-2025 | 0.83 $* | 0.89 $* |
| Jan-19-2025 | 0.34 $* | 0.19 $* |
Характеристики
Products Description
ENGINE | ||
Emission Standard | Tier 3/ Stage III | |
Make /Model | LAIDONG/3TE30 | |
Power /Rotation speed | 22.1kw(30HP)@2300rpm | |
Number of cylinder | 3 | |
TRACK SYSTEM | ||
Maximum Travel speed | 2.5km/h | |
Width of track shoe(Rubber &steel track) | 230mm | |
Number of track shoe per side(steel track only) | 38pcs | |
Number of upper roller per side | 0 | |
Number of bottom roller per side | 4 | |
PERFORMANCE PARAMETER | ||
Standard Bucket capacity | 0.1m³ | |
Swing speed | 12rpm | |
Maximum Grade ability | 30° | |
Maximum Bucket digging force | 15.3KN | |
Maximum Arm digging force | 10.5KN | |
Hydraulic system pressure | 18Mpa | |
Machine weight | 2200kg | |
Boom length | 1850mm | |
Arm length | 1000mm | |
MACHINE SIZE | ||
Overall dimension (L*W*H) | 4170mm*1300mm*2280mm | |
Axle base(Track length on ground) | 1230mm | |
Track gauge | 1070mm | |
Minimum Ground clearance | 230mm | |
Swing radius at tail | 1180mm | |
WORKING RANGE | ||
Maximum Digging height | 3700mm | |
Maximum Dumping height | 2290mm | |
Maximum Digging depth | 2450mm | |
Maximum Vertical digging depth | 2160mm | |
Maximum Digging radius | 4370mm | |
Minimum swing radius | 2020mm | |
Maximum Lifting height of blade | 240mm | |
Maximum Cutting depth of blade | 310mm | |
Boom swing angle(Left/Right) | 70°/50° | |
The mini crawler excavator is a compact excavator ,which Adopted the KOOP engine with EURO V emission , the boom of excavator can
swing to left or right , suitable for different director digging for your working , fitted famous brand main pump and valves ,
fitted international brand driving motor and slewing motor, hydraulic pilot servo operation system, with rubber track, with
hydraulic broken pipeline system.the machine can changed track from rubber to steel and cabin from open to closed.ensure it can
work in different working environments and conditions.
Compact, light and small turning radius, are its unique structural features; which makes it plays a biggest role in limited
working sites.
Features:
*Excavator by high efficiency , safety, convenience, beauty.
*Rubber track, with dozer blade.
*Mechanical handle controlling system.
*Engine with EURO V emission.
*Hydraulic pilot servo operation system, easy to operation ,
*Compact size meet the small working space.
swing to left or right , suitable for different director digging for your working , fitted famous brand main pump and valves ,
fitted international brand driving motor and slewing motor, hydraulic pilot servo operation system, with rubber track, with
hydraulic broken pipeline system.the machine can changed track from rubber to steel and cabin from open to closed.ensure it can
work in different working environments and conditions.
Compact, light and small turning radius, are its unique structural features; which makes it plays a biggest role in limited
working sites.
Features:
*Excavator by high efficiency , safety, convenience, beauty.
*Rubber track, with dozer blade.
*Mechanical handle controlling system.
*Engine with EURO V emission.
*Hydraulic pilot servo operation system, easy to operation ,
*Compact size meet the small working space.
Company Profile
TITECO is a global producer of construction equipment and vehicles, which is specialist in road building, repair and maintenance machinery equipment and vehicles. We offer our customers technologically first-class quality products, creative design services and sound service for optimum, economic production processes. With over 20 years experience in concrete & asphalt road building and maintenance, TITECO's applied technology service will help you to improve your performance. All our products are synonymous of power and stability, always provide the innovative solutions for complex issues.
Our Advantages
1. More than 20 years of cutting edge innovation and expertise help us to provide you all the best solutions of your projects.
2. With all kinds of our products commissioned for the concrete and asphalt industry projects,we believed that we know the cares and concerns of our customers well.
3. TITECO manufactures all equipment in our own factory under the strick quaility control system, makes the equipment much more reliable.
Production Process
Partner
Product Packaging
FAQ
Could you guarantee the quality of your products?
Quality control system certified with ISO 9001, All equipments under the strick quaility control system.
Quality control system certified with ISO 9001, All equipments under the strick quaility control system.
What is the MOQ?
In order to help our clients have a good understanding of the product, we can start order from 1 Unit.
In order to help our clients have a good understanding of the product, we can start order from 1 Unit.
I cannot find the suitable model, can I ask for a special model I need?
Sure. Kindly please advising the detail specification you need, we will make it according to your request.
Do you offer guarantee for the products?
Yes, we offer 1-years warranty for all equipment dated from the delivery.
Yes, we offer 1-years warranty for all equipment dated from the delivery.
What are your payment terms?
30% TT as deposit,70% TT before Shipment.
30% TT as deposit,70% TT before Shipment.
What about the lead-time?
Normally 15-30 working days after receiving the down payment.
Normally 15-30 working days after receiving the down payment.
Is it all right to make customer's own brand name?
We can be your OEM manufacture with your authorization of brand.
We can be your OEM manufacture with your authorization of brand.
