Сварочный аппарат SWTNSGM2 Geomembrane сварочный HDPE LDPE
- Категория: Earthwork Products >>>
- Поставщик: Hebei,Boda,Plastic,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 2142.44 $* | 2249.41 $* |
| Aug-17-2025 | 2124.26 $* | 2230.18 $* |
| Jul-17-2025 | 1782.8 $* | 1871.48 $* |
| Jun-17-2025 | 2088.83 $* | 2192.32 $* |
| May-17-2025 | 1818.35 $* | 1909.63 $* |
| Apr-17-2025 | 2052.12 $* | 2155.73 $* |
| Mar-17-2025 | 2034.55 $* | 2136.89 $* |
| Feb-17-2025 | 2016.50 $* | 2117.83 $* |
| Jan-17-2025 | 1998.50 $* | 2098.94 $* |
Характеристики
Porduct Feature
SWT-NSGM2
It adopts advanced hot air heating systemWith small,high speed,it perfects the welding quality even if corrosive material and bad working evironment.This machine is specially designed for tunnels subway,waterconservancy,aquaculture,biogas plants,landfills,chemcial mining.sewage treatment,roff construction and other waterproffing projects.a.The control of this series adopt PID automatic thermostatic control with high control and low temperature fluctuation.
b.Speed control of this series adopt PWM automatic voltage and regulation speed circuit.
c.Direct current servo the motor drive with great output torque and staple performance in walking.
d. This series of welding machine is excellent in performance and easy for operating.with high welding speed and good work quality.
b.Speed control of this series adopt PWM automatic voltage and regulation speed circuit.
c.Direct current servo the motor drive with great output torque and staple performance in walking.
d. This series of welding machine is excellent in performance and easy for operating.with high welding speed and good work quality.
Technical Parameters
Parameters of Hot Wedge Welding Machine:
MODEL | SWT-NSGM2 |
INPUT VOLTAGE | 220V/110V,50/60HZ |
POWER | 1200W |
WEIGHT | 7.5KG |
OVERLAP WIDTH | 12CM |
WELDING SPEED | 0.5-8m/min |
TEMPERATURE | 20-450℃ ADJUSTABLE |
SAEM WIDTH | 15MM*2 INTERIOR CAVITY |
WELDING THICKNESS | 0.2-2.0MM |
SWT-NSGM2 Parameter Settings | Reference Speed | Reference Temperature | Reference Pressure Value (When upper and lower pressure roller in 0 pressure state) |
HDPE 0.75mm | 2.5-4 | 350-380 | Counterclockwise adjustment is recommended at 4 |
HDPE 1.0mm | 2.0-3.5 | 380-420 | Counterclockwise adjustment is recommended at 3 |
HDPE 1.5mm | 2.0-3.0 | 380-420 | Counterclockwise adjustment is recommended at 2 |
HDPE 2.0mm | 1.5-2.5 | 400-420 | Counterclockwise adjustment is recommended at 1 |
Products Pictures
Operation Video
Application of Hot Wedge Welding Machine:
Geomembrane Welding Machine can weld geo-membrane of various thickness and are applicable for welding of all thermal-fused material such as PE,PVDF,LDPE, PVC, HDPE, EVA, PP and HDPE,EVA,PP.
Geomembrane Welding equipments are designed for water conservancy,aquaculture,landfills,chemical mining,sewage treatment,roof construction, and other waterproofing projects.
Geomembrane Welding Machine can weld geo-membrane of various thickness and are applicable for welding of all thermal-fused material such as PE,PVDF,LDPE, PVC, HDPE, EVA, PP and HDPE,EVA,PP.
Geomembrane Welding equipments are designed for water conservancy,aquaculture,landfills,chemical mining,sewage treatment,roof construction, and other waterproofing projects.
Packing & After-Sales Service
International warranty 24months.
Any parts broken or does not work under normal operating,we are free to provide.
Any parts broken or does not work under normal operating,we are free to provide.
