Новый гусеничный бульдозер Высококачественная Строительная площадка тяжелый на

Цена:83 000,00 $*

Количество:

PRODUCT PARAMETER

Hydrostatic system delivers higher efficiency and ma output traction force of 280KN. for 816, 350KN for 822.

Maintenance costs are reduced by 60% when compared competitors with torque converter and transmission design.

Counter-rotation and power turn feature delivers exc maneuverability on job sites.

Counter rotation—Tracks counter rotate to provide best in class maneuverability.

Powered turn-Machine maintains full power through turns to increase productivity.

Cruise control—Operators can retain previous speed settings which makes operation easily

Multi-function joystick allows for counter-rotation, powered turn and cruise control.

SU blade combines the excellent penetration of the S blade and the high production capacity of the U blade.

Designed for superior load retention and penetration in tightly packed materials.

L-shaped push arms bring the blade closer to the machine, providing excellent maneuverability, balance and blade penetration.

Blades feature a strong box section design, made from high tensile strength steel to stand up to the most severe applications.

Model
Operating Weigh t	28,5+0 kg
Ground Pressure	43.8 kPa
Ground Clearance	400 mm
Max.Slope	30°
Engine
Model	Weichai WP12G250E305
Rated Power	183 kW / 245 hp
Working Tool
Blade Type	S
Blade Capacity	12.7 m³
Blade Width	4,510 mm
Blade height	1,945 mm
Max. Blade Digging Depth	665mm
Max. Blade Lift Ground Clearance	1,165 mm
Max.Output Rimpull	350 kN
Maximum Digging Depth Of Ripper	N/A
Maximum Clearance Under Tip	N/A
Powertrain
Type	Electronic control, Dual-path, Hydrostatic Drive
Travel Speed- F/R	0 - 10 km/hr (Infi nitely Variable Speed Control)
Steering & Brake	Hydrostatic Steering, Wet, Multiple-Disc Brakes
Minimum Streeing Radius	4,300 mm (Counter-rotated avaliable)
Undercarrige
Track Shoe Width	915 mm
Track Shoe Quantity	45 piece
Length Of Track On Ground	3,488 mm
Track Gauge	2,340 mm
Track Roller Quantity	8/Side
Carrier Roller Quantity	2/Side
Hydraulic System
Type	Pilot Control
Implement Hydraulic System Pressure	19 Mpa
Service Refi ll Capacities
Cooling system	45 L
Hydrostatic Oil	160 L
Implement Oil	60 L
Fuel	460 L
Pivot Shaft Case (each side)	45 L
