Flap Steel Turnstile Factory Wholesale Top Ranking Products Security Door Flap Barrier



product description




.jpg


wsy237







.jpg


.jpg


TDZ-Y237





1. Fault detection and alarm functions, easy to use and maintenance

2. The running status can be programmed and controlled with the built-in keyboard on the main board

3. Mechanical anti-pinch function. If the gate meets resistance in the reset process, motors will stop working automatically within the prescribed time and reset again after the default delay (till fully reset)

4. Anti-breakthrough function. The gate is locked automatically until opening signal received

5. Support infrared photocell for anti-pinch and reset function

6. Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds), the system will cancel the authority of the current user automatically

7. Gate can be set as normally open or normally closed

8. Can be used with variety of card readers: IC / ID card readers, bar codes, fingerprints, etc. (Access controller needed)

9. Direction can be set as single-direction or bi-direction

10. LED direction indicator

11. Gate auto opens when power off and auto close when power on

12. Alarm function, in case of illegal intrusion and reverse intrusion, etc.





































































Size



1500mm*300mm*1000mm



Material



304 Stainless steel, 1.5 mm thickness



Panel material



Acrylic 15mm thickness



Motor type



DC 24V



Sensor



5 pairs



Lane width



≤600mm



Net weight



50kg/unit



MCBF



>5.000.000 times



Signal



Dry contract



Access speed



35 people/min



Open/Close speed



0.2 sec



Automatic reset time after failure



5sec (adjustable)



Working environment



Indoor / Outdoor (Under  shed)



Temperature



-25℃ --+70℃



Relative humidity



<90% no condensation



1) Architectural esthetic design, high quality brushing 304SS, stainless steel frame


2) Modular assembly provides for moving turnstiles in through confined routes for final installation.


3) Integration with any identification or access control system.


4) Heavy-duty high precision mechanism Nickel Plate for high corrosion resistance


5) Flexible extendibility. Operated by access control system and manual control both are available.


.jpg


.jpg













Company Information





Shenzhen Tongdazhi Technology Co., Ltd.


>Established in 2009.


>National high- tech enterprise integrating R&D, production, sales and service.


> One-stop service provider solutions for intelligent access control gate.


>Design&develop advanced access control systems.


>Independent import&export rights.


>Sold in more than 80 countries&regions.


.jpg


Our Advantages:


1.13 years of access control system solution service supplier.
2.Enterprise with patented technology for the whole industry of access turnstile gates.
3.Enterprise with the patents for a full range of the same style of access turnstile gate.
4.Possess technology enterprise certificate, ISO quality system management certification.
5.The product with CE, SGS certification, and the Department of Public Safety test report.
6.Support secondary development and customization of hardware and software such as access turnstile gates, access control, face recognition, etc.
7.Appearance design patent, movement utility new model patent, gate control board patent.
8.Software patents of Smart scenic spot ticket sales system, Smart building cloud visitor system, Smart community system, All-in-one card management system, etc.


.jpg


.jpg





related products


.1883.jpgFlap Bairrer-Y228.jpg_20190618161852.jpg








FAQ


1.Can machines be used outside?


With waterproof function, can be used outside well.


2.What is the warranty for the machine?


Whithin 12 months, if any problems, we will offer the accessories free.


3.When will you make the delivery?


Our production is 3-5 days. Bulk quantity may different.


4.How does your factory control the quality?


We have professional QC apartment. each order will be examined before delievery.


5.What is your MOQ?


Any quantity is acceptable.


6.Payment term?


30% by T/T, 70% by T/T before delivery.  Paypal, Western union and Money Grame are acceptable.
