От известного бренда оборудование для бетонных работ модель SY206C-8Y(V) 6M3 Автобетоносмеситель с импортный


Поделиться:


Цена:33 000,00 $ - 35 500,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-18-2025 39270.54 $* 41234.82 $*
Aug-18-2025 38940.73 $* 40887.1 $*
Jul-18-2025 32670.21 $* 34304.18 $*
Jun-18-2025 38280.44 $* 40194.18 $*
May-18-2025 33330.26 $* 34997.56 $*
Apr-18-2025 37620.75 $* 39501.65 $*
Mar-18-2025 37290.34 $* 39155.13 $*
Feb-18-2025 36960.75 $* 38808.50 $*
Jan-18-2025 36630.84 $* 38462.54 $*

Характеристики









































 Famous Brand Concrete Machinery Model SY206C-8Y(V) 6M3 Truck Mixer With Imported Engine









Product Description





Main Features:


Specialized Cab
Safe and secure
Built for the driver
Convenient ACCESS maintenance
Attractive styling
Panoramic monitoring (optional)





Improved Braking
By making full use of exhaust valve braking technology, braking distance has been reduced by 15% and brake lining wear is decreased by 50%. The product uses a high volume air compressor, high quality piping, and new sealing technology that shortens air build up time and brake response time.





Energy-saving Technology
The engine dual power mode, coupled with the unique intelligent transmission's power matching technology makes a 10% fuel savings.





Low Deck Technology
The frame is made of high-strength special steel plates, improving reliability and safety. It uses original subframe-free structure combined with the hollow front and back-end structure design, reducing the center of gravity by 100mm and making the vehicle lighter.





Leading Edges Steering Technology
The large displacement power steering pump reduces operator effort by 40%. Optimizing chassis geometry and front axle steering angle reduces the minimum turning radius by 15%.





Anti-buildup Technology
The three section blade provides an efficient discharge angle.
The flushing device, an innovative front taper and ball-crown connecting structure are installed at the rear taper, in order to clear stagnant aggregate from the dead space, and to prevent aggregate from piling up at front and rear tapers. Due to this, the residual rate at the discharge port declines to 0.4%.





Smart Operating Technology
Each truck is equipped with a GPS system, which boasts five functions including vehicle monitoring, record/playback, alarm reporting, fleet management, statistics and analysis. With this information you can keep abreast of the mixer truck's location, maintenance items, discharge, etc.





Maintenance Tips
Dashboard mounted monitor provides maintenance alarms for the truck's key components such as engine, axle, and transmission in order to facilitate maintenance scheduling.


















































































































Rudder DirectionLeft
Curb Weight(kg)8000
GVW(kg)22400
Dimension (L×H×W)(mm)7530×2320×3320
Wheel Base(mm)4200
Min. Ground Clearance(mm)≥225
Min. Turning Diameter(m)16
Fuel Consumption(L/100km)≤ 25
Braking Distance(V0=30km/h)(m)≤10(Full load)
≤9(Empty load)
Bore(mm)×Stroke(mm)φ112×120
Displacement(L)4.73
Rated Power/Rev Speed(kW/rpm)105/2500
Max. Torque/Rev Speed(N.m/rpm)500/1300~1800

Capacity(m3)4
Feeding Speed(m3/min)≥ 3
Discharge Speed(m3/min)≥ 2
Discharge Residual Rate≤0.5%
Slump(mm)50~210
Water Tank Capacity(L)300
Water Pressure(MPa)0.35~0.38
ReducerTOP T60
Hydraulic PumpHP4VC45HW
MotorHAA2FM56
Engine ModelYC4EG140-50
Gear-boxFast 8JS75F
Front Axle(t)3.2
