Пластиковый гибкий цепной конвейер с алюминиевой рамой для транспортировки

Описание и отзывы

Трекер стоимости

Характеристики

Product Name	Flexible Chain Conveyor Machine
Brand Name	Hairise
Conveyor type	Chain Conveyor
Belt type	flexible chain
Feature	Lifting transportation
Shipping Port	Shanghai,China
Frame Material	SS304/Carton steel/Aluminium
Dimension	Customized
Length	0.5-100m
Height	200-1000mm Adjustable
Speed	Adjustable(1-60 M/min)
Color	as your required
Load Capacity	500-1000kg
Voltage	220V/380V/415V
Hertz	50HZ/60HZ
Motor	SEW/ABB/Marble/Liming....
Frequency	Delta/Danfoss/Siemens...
Package	Wooden box
Produce time	About 45 working days after getting payment
Warranty	3 years for conveyor,1 year for replacement parts
After sale service	Engineers available to service machinery oversea





Feature:
1: Application in the conveyor of tinplate bottle, the conveyor of PET bottle and the conveyor of aluminium pot, storage platform and conveying of edge. It is suitable for small things passing. It also suitable for the conveying of medicine, cosmetics, and small food .

2: The temperature of POM :-40°C~+90°C

3:The temperature of PP:+1°C~+98°C(suitable for the environment of sour)

This kind of modular belt can be used in following industries:

1. Industry application: tobacco industry, logistics industry, glass industry, medicine and chemical industry.

2. Fruit & vegetable & dairy & applications: elevators, inspection tables and packaging lines

3. Beverage industry such as acceleration, beer, soft drink, milk and accumulation.

4. Bakery applications: raw dough handling, cooling lines and packing lines

5. Meat industry such as tray pack line and metal detectors.

6. Food industry such as cool off lines and pack lines.

7. Can making/filling lines and accumulation tables

8. Spiral applications as proofing and freezing

9. Meat & poultry applications: packaging lines

10. Seafood applications: tray packing lines

11. Other fields related to plastic  modular belt.



Main product:

Slat top chain:

Large selection of straight running and side flexible chains, available in steel or thermoplastic materials, enabling solution for any application

Stainless steel and plastic slat top chains, rubber top chains, roller top chains.

Modular belt:

Complete range of modular belts and chains, offered in different pitches (from 8 mm pitch to 2") and top surface execution, to suit any application

Flat Top Belt has a smooth surface without holes (used to transport general products).

Perforate Flat Top Belt has an overall appearance similar to the flat top but has a slot hole for ventilation and liquid.

Flush Grid Belt is commonly used in production lines that require cleaning of materials and for cooling. There are openings> 20% of the belt area. Designed to drain water and air

Raised Rib Belt. There are thin ridges along the longitudinal belt of some models. Wear a Finger Plate to connect between the belts. Which the thin ridge raised Is to reduce the friction of the material with the belt surface

Rubber Top Belt is the use of rubber (Rubber) to be attached to the belt. To help prevent slipping of the material while conveying in a vertical position

Roller Top Belt is used to convey and change the direction of the packing (Sorting) of the package.

Modular belt:

Complete range of modular belts and chains, offered in different pitches (from 8 mm pitch to 2”) and top surface execution, to suit any application

Plastic modular belts: POM/PP flush grid belt, flat top belt, raised rib belt, anti-skid rubber top belt, roller top belt, stainless steel mesh belt and dynamic transition belt.

Gripper chains, therein included an extremely advanced maintenance-free gripper chains range;

Sprocket:

Available in moulded and machined versions, solid and split

Customize for Teeth number, DF and outer diameter is available.

Conveyor Components

Lubricated and standard wear strips and other popular components.

Chain guides, return rollers, side guides, product handling and supporting components

Corner tracks: Magnetic, TAB, Bevel curves, and Low pin center curves, both standard and custom-made;

Conveyor:

Plastic flexible chain conveyor, chain conveyor, chain network conveyor, metal mesh conveyor, modular belt conveyor, PVC/PU conveyor, roller conveyor, straight conveyor, curved conveyor, double rail conveyor, upgrade conveyor, screw conveyor, inclined conveyor, powered or without power conveyor.
