Морской резиновый шланг Гибкие шланги для топливного масла
- Категория: Other Marine Supplies >>>
- Поставщик: Qingdao,Florescence,Marine,Supply,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 893.82 $* | 938.75 $* |
| Aug-16-2025 | 885.10 $* | 929.4 $* |
| Jul-16-2025 | 743.36 $* | 780.46 $* |
| Jun-16-2025 | 870.90 $* | 914.70 $* |
| May-16-2025 | 758.39 $* | 796.71 $* |
| Apr-16-2025 | 855.90 $* | 898.95 $* |
| Mar-16-2025 | 848.97 $* | 890.19 $* |
| Feb-16-2025 | 840.80 $* | 882.48 $* |
| Jan-16-2025 | 833.88 $* | 875.61 $* |
Характеристики
Product Description
Marine hose rubber fuel oil hoses for ship to ship
Application: Used for port, dock seawater silt sand discharge flood etc.
Characteristics: Flexible, Anti-waves, Wear-resistance, Weather-resistance, Aging-resistance, seawater resistance
Temperature: From -20 Degrees Celsius To 80 Degrees Celsius.
Guarantee period:1 year
Structure:
Internal rubber layer: NR, SBR,BR
Reinforcement layer: high tensile textile braided or tire cord or steel wire spiral
External rubber layer Black SBR and CR blend rubber with orange attention line.
W.P: 10-30 bar
Characteristics: Flexible, Anti-waves, Wear-resistance, Weather-resistance, Aging-resistance, seawater resistance
Temperature: From -20 Degrees Celsius To 80 Degrees Celsius.
Guarantee period:1 year
Structure:
Internal rubber layer: NR, SBR,BR
Reinforcement layer: high tensile textile braided or tire cord or steel wire spiral
External rubber layer Black SBR and CR blend rubber with orange attention line.
W.P: 10-30 bar
Different types of oil hose
Specification
Inner Diameter | Wall Thickness | Working Pressure | Burst Pressure | Strength Tensile | ||
Inch | mm | mm | psi | psi | kg | |
1 | 25.4 | 2.2 | 300 | 900 | 2286 | |
1 | 25.4 | 2.5 | 400 | 1200 | 2286 | |
1 1/2 | 38.1 | 2.2 | 200 | 600 | 2858 | |
1 1/2 | 38.1 | 2.8 | 300 | 900 | 3429 | |
2 | 50.8 | 2.4 | 200 | 600 | 4000 | |
2 | 50.8 | 3.0 | 300 | 900 | 4572 | |
2 1/2 | 63.5 | 2.5 | 175 | 525 | 4572 | |
2 1/2 | 63.5 | 3.0 | 300 | 900 | 5715 | |
3 | 76.2 | 2.7 | 175 | 525 | 6286 | |
3 | 76.2 | 3.2 | 250 | 750 | 7143 | |
4 | 102 | 3.0 | 150 | 450 | 10000 | |
4 | 102 | 3.5 | 200 | 600 | 11715 | |
5 | 127 | 3.0 | 150 | 450 | 12286 | |
5 | 127 | 3.8 | 200 | 600 | 14572 | |
6 | 152 | 3.2 | 150 | 450 | 15143 | |
6 | 152 | 4.3 | 200 | 600 | 18000 | |
8 | 203 | 3.3 | 150 | 450 | 19715 | |
8 | 203 | 4.5 | 200 | 600 | 22858 | |
10 | 254 | 3.8 | 150 | 450 | 35715 | |
10 | 254 | 4.8 | 200 | 600 | 42286 | |
12 | 305 | 4.0 | 150 | 450 | 63143 | |
Advantages of oil hose
Wear indicating layer
Independent foam floating casing preventing water absorption
Outer layer with excellent resistance of abrasion UV, aging and corrosive enviroments
Easy installation and less maintenance
Customized steel flange are available
Independent foam floating casing preventing water absorption
Outer layer with excellent resistance of abrasion UV, aging and corrosive enviroments
Easy installation and less maintenance
Customized steel flange are available
