Сертификат Ce Self-повышение башенный кран 8 тонн SFT125(T6016-8) подъемно-транспортное
- Категория: Tower Cranes >>>
- Поставщик: Sinomada,Heavy,Industry,(Changsha),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 11900.86 $* | 12495.78 $* |
| Aug-19-2025 | 11800.27 $* | 12390.92 $* |
| Jul-19-2025 | 9900.73 $* | 10395.17 $* |
| Jun-19-2025 | 11600.50 $* | 12180.36 $* |
| May-19-2025 | 10100.48 $* | 10605.52 $* |
| Apr-19-2025 | 11400.39 $* | 11970.96 $* |
| Mar-19-2025 | 11300.19 $* | 11865.49 $* |
| Feb-19-2025 | 11200.14 $* | 11760.69 $* |
| Jan-19-2025 | 11100.35 $* | 11655.62 $* |
Характеристики
Ce Certificate Self-raising Tower Crane 8 ton SFT125(T6016-8) Hoisting Machinery
Mobile/Whatsapp/Wechat:+86 17369285626
Instagram/Facebook:Pearl Wang
e-mail: pearl@sinomada.com
Product Description
Flat top tower crane
Superior performance
Tower group anti-collision technology
Distributed control system
| SFT125(T6016-8) | SFT160(T6518-10) | SFT258(T7021-12) | SFT315(T7530-16) | SFT600(T8040-25) | |
Max Lifting Capacity | 8T | 10T | 12T | 16T | 25T |
Max Lifting Moment | 125t·m | 160t·m | 258t·m | 315t·m | 600t·m |
Free Standing Height | 40.5m | 47m | 60m | 60m | 78m |
Max Jib Length | 60m | 65m | 70m | 75m | 80m |
The Max Height under Hook | 222m | 268.2m | 260m | 315m | 339m |
Tip Load at Max Jib Length | 1.6T | 1.8T | 2.1T | 3T | 4T |
The Speed of Slewing Mechanism | 0-0.6r/min | 0-0.7r/min | 0-0.8r/min | 0-0.7r/min | 0-0.7r/min |
The Speed of Hoisting Mechanism | 0-90r/min | 0-100r/min | 0~88r/min | 0-129r/min | 0-100r/min |
The Speed of Luffing Mechanism | 0-60r/min | 0-60r/min | 0~75r/min | 0~80r/min | 0~100r/min |
The Power of Slewing Mechanism | 2x4kW | 2x5.5kW | 2×7.5kW | 2*7.5kW | 3*7.5kW |
The Power of Hoisting Mechanism | 30kW | 45kW | 55kW | 67kW | 95kW |
The Power of Luffing Mechanism | 4kW | 5.5kW | 5.5kW | 7.5kW | 11kW |
Power Voltage | 380V | 380V | 380V | 380V | 380V |
Power Frequency | 50Hz | 50Hz | 50Hz | 50Hz | 50Hz |
Packaging & Shipping
