Штук в одной партии eMBB-Оптимизированный 5G Sub-6 ГГц M.2 модули RM500Q-GL беспроводной

RM500Q-GL 5G Cellular Modem is a cellular 5G module optimized specially for IoT/eMBB applications. Adopting the 3GPP Rel. 15 LTE technology, it supports both 5G NSA and SA modes.

This is a 5GNR 4×4 MIMO, 4G LTE capable, sub 6Ghz bands only modem. This version does not support mmWave 5G frequencies.

Designed in an M.2 (key B) form factor the RM500Q-GL fits in the same slot type as the LTE-A Cat 6 module EM06, Cat 12 module EM12, and Cat 16 module EM160R. This helps facilitate customers to migrate from LTE-A to 5G.

NOTE:

The global version RM500Q-GL nearly covers all the main stream carriers worldwide. See the Cellular Band Info tab for more details.

The module supports Qualcomm® IZat™ location technology Gen8C Lite (GPS, GLONASS, BeiDou and Galileo). The integrated GNSS receiver greatly simplifies product design and provides quicker, more accurate and more dependable positioning capability.

A rich set of Internet protocols, industry-standard interfaces and abundant functionalities (USB/PCIe drivers for Windows 7, Windows 8/8.1, Windows 10, Linux, Android) extend the applicability of the module to a wide range of M2M and IoT applications such as industrial router, home gateway, STB, industrial laptop, consumer laptop, industrial PDA, rugged tablet PC, video surveillance and digital signage.

Key  Benefits

• 5G/4G/3G Multi-mode module with M.2 form factor, optimized for IoT and eMBB applications


• Supports ENDC 3x carrier aggregation and 256QAM, DL Cat 16/ UL Cat 18


• Worldwide 5G and LTE-A coverage


• Both NSA and SA modes


• Multi-constellation GNSS receiver available for applications requiring fast and accurate fixes in any environment


• Feature refinements: DFOTA and VoLTE (optional)


• 5G DL 4×4 MIMO, UL 2×2 MIMO


• 4G DL 4×4 MIMO


• LTE LAA B46 Support




  Supported Frequency Bands


















































  5G	5G NR	3GPP Release 15 NSA/SA operation, Sub-6 GHz
  	5G NR NSA	n38/n41/n77/n78/n79
  	5G NR SA	n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/ n48*/n66/n71/n77/n78/n79
  	MIMO	DL: 4 × 4 MIMO on n1/n2/n3/n7/n25/n38/n40/n41/ n48*/n66/n77/n78/n79 UL: 2 × 2 MIMO on n41/n77/n78/n79
  LTE	LTE Category	DL Cat 16/ UL Cat 18
  	LTE-FDD	B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/ B20/B25/B26/B28/B29/B30/B32/B66/B71
  	LTE-TDD	B34/B38/B39/B40/B41/B42/B43/B48
  	LAA	B46
  	DL 4 × 4 MIMO	B1/B2/B3/B4/B7/B25/B30/B32/B34/B38/B39/B40/B41/B42/B43/B48/B66
  UMTS	WCDMA	B1/B2/B3/B4/B5/B8/B19
