Прямые продажи с фабрики 6615JB2002A SW-102T LG контроллер в сборе размораживания датчик холодильник морозильная
- Категория: Refrigerator & Freezer Parts >>>
- Поставщик: Ningbo,Lingtong,Electric,Appliance,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.14 $* | 0.91 $* |
| Aug-16-2025 | 0.17 $* | 0.28 $* |
| Jul-16-2025 | 0.67 $* | 0.75 $* |
| Jun-16-2025 | 0.69 $* | 0.42 $* |
| May-16-2025 | 0.51 $* | 0.88 $* |
| Apr-16-2025 | 0.15 $* | 0.43 $* |
| Mar-16-2025 | 0.46 $* | 0.17 $* |
| Feb-16-2025 | 0.38 $* | 0.72 $* |
| Jan-16-2025 | 0.27 $* | 0.0 $* |
Характеристики
Factory Direct Sales 6615JB2002A SW-102T LG Controller Assembly Defrosting Sensor Refrigerator Freezer
Specification
ltem NO. | ST-004 3036B |
Use | Defrost/Temperature control/Protection |
Appliance | Refrigerators, Freezer |
Reset type | Automatic |
Basic material | Bakelite, Copper, Silver |
Amperage | 5A |
Max. Operating Temperature | 90°C |
Differential | According to the requirement |
Min. Diff | 8°C |
Tolerance | Refer to the regulation |
Cold-resistant Temperature | -30°C |
Limit of the tolerance(OFF) | ±3°C |
Limit of the tolerance(ON) | ±3°C |
Contact material | Silver |
Dielectric Strength | Parts between electriferous components and non-electriferous ones can bear 2000V (3750V for Reinforced insulation type) 50Hz AC current, which is nearly sine wave, for one minute as bearing test. Resulted no breakdown, no flashover. |
Insulation Resistance | With a DC 500V megger, borne DC 500V, the tested value is over 10MW. |
Resistance Between Terminals | Below 50mW |
Temperature characteristics | Normal close, Normal open |
Maximum Ambient Temperature | 90°C |
Diameter of Bimetal Disc | F12.7mm(1/2″) |
Tube Color | Pink |
Terminal type | Customized (Refer to our specification) |
Cover/Bracket | Customized (Refer to our specification) |
