Горячая Распродажа & высокое болт гайка холодной высадки лучшее качество Автоматическая мульти станции частей формируя
- Категория: Metal Forging Machinery >>>
- Поставщик: Changzhou,Kangdate,Lubrication,Powder,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 68877.36 $* | 72321.70 $* |
| Aug-16-2025 | 68298.82 $* | 71713.85 $* |
| Jul-16-2025 | 57301.9 $* | 60166.76 $* |
| Jun-16-2025 | 67141.71 $* | 70498.33 $* |
| May-16-2025 | 58459.37 $* | 61382.83 $* |
| Apr-16-2025 | 65983.11 $* | 69282.69 $* |
| Mar-16-2025 | 65404.98 $* | 68674.5 $* |
| Feb-16-2025 | 64826.33 $* | 68067.0 $* |
| Jan-16-2025 | 64247.72 $* | 67459.64 $* |
Характеристики
Product Description
Product Detail
| Material | metal |
| Color | BLUE/CUSTOMIZED |
| Function | COLD HEADING |
| Feature | 4 DIE4 BLOW |
| Usage | for screw making |
| Packing | film wrapped |
Model | KDT -63S |
Forging Station | 3 |
Maximum Cut off Diameter (mm ) | 8 |
Maximum Cut off Length (mm) | 60 |
Speed max (pcs/min ) | 250 |
P .K.O stroke (mm) | 12 |
K.O stroke (mm) | 52 |
Main motor (kw) | 11 |
Cut-off-die diameter(mm) | Φ 30 |
Punch die size(mm) | Φ 40*90L |
Main die size (mm) | Φ 50*85L |
Dies pitch(mm) | 60 |
Forging power (Ton ) | 40 |
Approx weight (ton) | 7 |
Normal bolt size(mm) | 3-6 |
Shank length of blank | 10-50 |
Model | KDT -104S |
Number of Heading Station | 4 |
Maximum Cut off Diameter (mm) | 12 |
Maximum Cut off Length (mm) | 135 |
Product Shank Diameter (mm) | 6-10 |
Max Die kick out stroke (mm) | 115 |
Max punch knockout stroke (mm) | 20 |
Main Ram Stroke (mm) | 190 |
Main Die Size (mm) | φ75*135L |
Punch die dims (mm) | φ53*115L |
Cut-off die dims (mm) | φ45*59L |
Main motor power (KW) | 30 |
Output (pcs/min) | 90-140 |
Die pitch (mm) | 90 |
Forging power (Ton) | 85 |
Shank Length of blank (mm) | 15-110 |
Approx. Weight (ton) | 8 |
Model | KDT -134L |
Maximum Cut off Diameter (mm) | 15 |
Maximum Cut off Length (mm) | 190 |
Main motor power (KW) | 37 |
Product Shank Diameter (mm) | 8-12.7 |
Max punch knockout stroke (mm) | 30 |
Max Die kick out stroke (mm) | 160 |
Diepitch (mm) | 110 |
Cut off die dia | φ55 |
Punch Size (mm) | φ60*150 |
Main die dia | φ85*190 |
Normal size of bolt | 8-12.7 |
Shank length of blank | 30-155 |
Forging power(Ton) | 120 |
Approx. Weight (ton) | 25 |
Model | KDT-164S |
Number of Station | 4 |
Maximum Cut off Diameter (mm) | 18 |
Maximum Cut off Length (mm) | 195 |
Product Shank Diameter (mm) | 10-16 |
Max Die kick out stroke (mm) | 178 |
Max punch knockout stroke (mm) | 40 |
Main Ram Stroke (mm) | 260 |
Main Die Size (mm) | φ100*190L |
Punch die dims (mm) | φ75*185L |
Cut-off die dims (mm) | φ60*90L |
Main motor power (KW) | 55 |
Forging Power (Ton) | 210 |
Output (pcs/min) | 70-100 |
Diepitch (mm) | 120 |
Shank Length of blank (mm) | 70-100 |
Approx. Weight (ton) | 42 |
Model | KDT-254SL |
Number of Heading Station | 4 |
Maximum Cut off Diameter (mm) | 28 |
Maximum Cut off Length (mm) | 253 |
Output (pcs/min) | 40-70 |
Max punch knockout stroke (mm) | 40 |
Max Die kick out stroke (mm) | 205 |
Main Ram Stroke (mm) | 330 |
Main motor power (KW) | 100 |
Cut-off die dims (mm) | φ80*130L |
Punch die dims (mm) | φ120*270L |
Main Die Size (mm) | φ140*250L |
Diepitch (mm) | 174 |
Forging Power (Ton) | 420 |
Product Shank Diameter (mm) | 14-25.4 |
Shank Length of blank (mm) | 35-200 |
Approx. Weight (kgs) | 10800 |
