Membrane plate filter press secondary squeezing by compressed air



1.Brief introduction:

The membrane filter press ,whose filtration chamber is composed by membrane plate and the chamber plate ,with the help of the feeding pump,the solid and liquid are separated by the filter medium(filter cloth) .After the filter cake is formed,and then air or liquid goes into membrane plate.The second squeezing happens by membrane late bulk and lower moisure content.



Filter for viscous materials require higher moisture content and for users of this machine have their unique characteristics.

Plate with enhanced molded polypropylene, polypropylene plate with diaphragm mounted together, sturdy, secure, not easy fall off, long service life



Advantages of membrane filter press:



- High product throughput
- Reduction of the residual moisture of the filter cake
- Shorter filtration, wash and cake cycles
- Drier cakes means energy saving on cake drying and transportation
- The optimized cake structure facilities quicker and better washing results
- Varying product quantities and compositions present no problems to the membrane filter press

-  High degree of automation, labor-saving and ease to operate:adopting PLC control system, including automatic keeping pressure, automatic  pulling board, quick program functions,ect.



Specifications and technical parameters of membrane filter press:



Type	(m2) Filter  area	(mm) Filter  plate  size	(mm) Filter  cake  thickness	(L) Filter  chamber  volume	(pcs) Filter  plate number	(Mpa) Filtrating  pressure	(kw) Motor  power	(kg) Weight	(mm) Dimension (L×W×H)
XG30/870-30U	30	870×870	30	427	23	0.6	4.0	2680	3490×1250×1300
XG40/870-30U	40			534	29			3050	3880×1250×1300
XG50/870-30U	50			676	37			3465	4400×1250×1300
XG60/870-30U	60			818	45			4003	4920×1250×1300
XG70/870-30U	70			960	53			4584	5240×1250×1300
XG80/870-30U	80			1103	61			5082	5760×1250×1300
XG50/1000-30U	50	1000×1000		665	27	0.6	4.0	4352	4270×1500×1400
XG60/1000-30U	60			808	33			4480	4770×1500×1400
XG70/1000-30U	70			950	39			5263	5130×1500×1400
XG80/1000-30U	80			1093	45			5719	5560×1500×1400
XG100/1000-30U	100			1378	57			6555	6410×1500×1400
XG120/1000-30U	120			1663	69			7466	7260×1500×1400



Pictures to show you principle of the second sequeezing process

01.After the filter cake are formed ,the diaphragm valve open and air or liquid (usually water)goes into the membrane plate





02.The membrane plate filled with air or liquid,so the membrane plate is expanded, this can make the second squeezing of the filter cake,and lower the moisture content



 Membrane plates of membrane filter press are made from RPP material moulded. Diaphragm and RPP are enchased togerher to become firm, so they do not fall off easily and have a longer service life.



Membrane plate of membrane filter press





Membrance matching plate of membrane filter press





Below device is used for the automatic type ,which can pulling plates one by one automatically ,we called the pulling plates device.

Plate shifting control switch of membrane filter press





Limit switch of membrane filter press







 Master control of membrane filter press
