Прямая продажа с фабрики латунь материал нормально открытый G3/4 дюйма вентиляции и кондиционирования воздуха регулятор расхода
- Категория: Flow Switches >>>
- Поставщик: Zhongshan,Qingong,Sensor,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 6.28 $* | 6.10 $* |
| Jul-16-2025 | 5.67 $* | 5.58 $* |
| Jun-16-2025 | 6.24 $* | 6.98 $* |
| May-16-2025 | 6.71 $* | 6.50 $* |
| Apr-16-2025 | 5.81 $* | 5.58 $* |
| Mar-16-2025 | 6.14 $* | 6.75 $* |
| Feb-16-2025 | 6.44 $* | 6.30 $* |
| Jan-16-2025 | 6.89 $* | 6.81 $* |
Характеристики
Company Profile
China, Guangdong Province
Zhongshan Qingong Sensor Technology Co., Ltd
Welcome you
We have 10 years of experience in the production of flow switches, Adhere to professional, focused, single-minded, customer-centered is the pace of our continuous progress, Each of our products has undergone rigorous testing, Let the customer get the quality guarantee in the use.
Working principle of flow switch
SK-FS06,Flow switch
When the flow pushes the distance between the stainless steel baffle and the 3~5mm, the outer induction rod will sense the magnet trigger signal (ON), on the inner swinging rod. When the flow rate is reduced below the minimum flow rate, the baffle automatically resets the disconnecting signal (OFF).
Flow switch parameters
Pipe Diameter(mm) | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | ||||||||
Flow increase（Brown blue closure）m3/h | 0.72 | 0.87 | 1.26 | 1.92 | 3.12 | 4.5 | 9.7 | 12 | 15.6 | ||||||||
Flow increase（Brown blue Disconnect）m3/h | 0.51 | 0.70 | 1.08 | 1.56 | 2.7 | 3.96 | 9 | 10.8 | 14.4 | ||||||||
Work pressure | 0.1~1.2MPa 1.5MPa(max) | ||||||||||||||||
Operating temperature | -20~150℃ 180℃（max) | ||||||||||||||||
Product weight | 200g | ||||||||||||||||
Name | Test Conditions | Units | Numerical value |
Resonant Frequency (typ) | Hz | 3200 | |
Switched Power (max) | W | 70 | |
Switched Voltage DC (max) | V | 200 | |
Switched Voltage AC, RMS value (max) | V | 250 | |
Switched Current (max) | mA | 1000 DC/AC | |
Breakdown Voltage (min) | V | 400 | |
Contact Resistance (initial max.) | enenrgization | mΩ | 90 (27 AT) |
Contact Resistance (initial typ.) | enenrgization | mΩ | 60 (27 AT) |
Contact Capacitance (max) | without test coil | pF | 0.2 |
Insulation Resistance (min) | RH ≤ 45% | mΩ | 106 |
Spot sale
Product detail
Stainless steel baffle
Use a 304 stainless steel baffle. When the baffle is too long, you can use scissors to cut the baffle to the length suitable for
you.
Buy 100 or more, and we can customize the shape and length of the baffle you want.you.
Conjoined copper head, no seam, no perforation, never leak, rest assured to use.
Permanent magnet.
Nd-Fe-B magnet, which can work at 180 ℃. When the dry Reed switch senses magnetism, it will output a signal.
Dry Reed Switch.
So that the switch has stable characteristics and extremely long service life. Compared with the general mechanical switch, the dry Reed has the advantages of simple structure, small size, high speed and long working life, and compared with the electronic switch, it has the characteristics of strong resistance to load impact and high reliability.
Professional flow switch
Packing picture
Apply in a wide range of areas
