Stroboscope Stroboscope DT series Digital Portable Stroboscope For Industrial Applications



The parts of product formation:

329 9 Party +key holder plate +lamp board display panel +adapter plate.



Application :

1. Stroboscope is mainly used to still images, observation overprint during the production process . Unique easy operation panel, portable, easy to use and design synchronization .

2. Widely used in packaging and  printing  industry, to check the printing quality,moulding,punching,folding.

3.It can also used for measuring the rotate speed of spindle ,line of Spinning machine in Textile industry.

4. Used in machinery machine building industry ,to test oscillation amplitude and vibration frequency

5.Used for aircraft manufacturing, automobile manufacturing, printing, mining, shipbuilding, steel cable, chemical, optical, medical and other industries.



Note :

1. In order to protect the strobe tube not damaged by the power impact, make sure eachpowering on interval over 10 seconds.



2. Pls , remember to recharging again after usage every time , make sure the usage for the next time



Function of product:

In stroboscopic instrument observation high speed rotation or movement of objects,by modulating stroboscopic flashing frequency, and the measured object rotating or moving close to the speed of the object to be measured and synchronization,while at high speed, but it is the slow motion or relative rest.The persistence of vision, so that everybody can easily observed by high-speed operation object status.

Attention:

1. Power supply plug slot inserted upwardly, plug sleeve do not screw tight, avoid the internal connection loosening caused by short circuit.

2. When the stroboscope can not work normally, unplug the power line, check the insurance tube.

3. When the strobe drain flash may be lamp aging, please timely replacement lamp.

4. The lamp after the power supply is cut off, and may be charged, non professionals are not allowed to open.

5. Handle with care, do not fall into the water or solvent, not in hot and humid or high environmental pollution.



Product Features:



Setting Accuracy	±0.01%
LED Spec	American CREE10W LED Light
Power	Above 300W
Wide flash range	60~12,0000FPM
Battery Specification	2000mA
LED Spec.and function	USA CREE 10W
Dimension	Customized





CERTIFICATE:

We have obtained the quality management system certificate of ISO9001:2008 and CE certificate. Besides, our digital tachometer stroboscopes have passed EMC test and other domestic test.
