Zoomlion 25 тонн ZTC250H431 грейфер Телескопический буксируемый прицеп мини грузовик монтируемый кран на
- Категория: Truck Cranes >>>
- Поставщик: Anhui,Heavy,And,Light,Industries,International,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 91035.42 $* | 95587.82 $* |
| Aug-17-2025 | 90270.67 $* | 94784.32 $* |
| Jul-17-2025 | 75735.75 $* | 79522.37 $* |
| Jun-17-2025 | 88740.81 $* | 93177.60 $* |
| May-17-2025 | 77265.48 $* | 81128.65 $* |
| Apr-17-2025 | 87210.61 $* | 91571.95 $* |
| Mar-17-2025 | 86445.33 $* | 90767.70 $* |
| Feb-17-2025 | 85680.90 $* | 89964.99 $* |
| Jan-17-2025 | 84915.30 $* | 89161.79 $* |
Характеристики
Product Description
Truck Crane ZTC250H431
New generation 4.0 series platform 25T with 4 section main boom(10.7m-35m).
Max. lifting moment reaches to 960kN.m, max. lifting height with jib up to 43m.
Higher operation/working speed.
Profitable return on investment
New generation 4.0 series platform 25T with 4 section main boom(10.7m-35m).
Max. lifting moment reaches to 960kN.m, max. lifting height with jib up to 43m.
Higher operation/working speed.
Profitable return on investment
Item | Unit | Value | Remarks | ||||
Working performance | Max. rated lifting capacity | kg | 25000 | ||||
Max. load moment of basic boom | kN.m | 960 | |||||
Max. load moment of main boom(fully extended) | kN.m | 672 | |||||
Max. lifting height of main boom | m | 35.4 | These parameters do not include deflection of main boom and jib | ||||
Max. lifting height of jib | m | 43 | |||||
Working speeds | Max. hoist rope speed(Main winch) | m/min | 120 | At the 4th layer | |||
Max. hoist rope speed(Auxiliary winch) | m/min | 120 | At the 4th layer | ||||
Boom derricking up time | s | 25 | |||||
Boom derricking up time | s | 64 | |||||
Slewing speed | r/min | 2.7 | |||||
Driving | Max. driving speed | km/h | 90 | ||||
parameters | Max. gradeability | % | 42 | ||||
Min. turning diameter | m | ≤20 | |||||
Min. ground clearance | mm | 260 | |||||
Limits for exhaust pollutants and smoke | Comply with related standards | GB3847-2005 GB17691-2005 National stage III | |||||
Oil consumption per hundred kilometers | L | 28 | |||||
Mass | Deadweight in driving condition | kg | 29600 | ||||
Complete vehicle kerb mass | kg | 29470 | |||||
Front axle load | kg | 6300 | |||||
Rear axle load | kg | 23300 | |||||
Dimensions | Overall dimensions(L×W×H) | mm | 13100×2500×3450 | ||||
Outrigger spread(L) | m | 5.4 | |||||
Outrigger spread(W) | m | 6.2 | |||||
Main boom length | m | 10.7-35 | |||||
Boom angle | ° | -82 | |||||
jib length | m | 8 | |||||
Offset | ° | 0/15/30 | |||||
Chassis | Model | ZLJ5324JQZ | |||||
Type | II | Code: ZLJ5324JQZV3 | |||||
Engine | Model | kw/r/min | WP7.270E31 | ||||
Rated power | n.m/r/min | 199/2100 | |||||
Max. output torque | 1160/1200～1600 | ||||||
Manufacturer | Zoomlion Heavy Industry Science and Technology Co., Ltd. | ||||||
