High Performance Car Used Coatings Micro Oval Gear Flow Meter



SUMMARIZE

The coating oval gear flow meter is a kind of micro flow meter.It's min flow is 0.5ml/min.

We focus on micro flow industry(liquid and gas).It used for oil hydraulic oil,water,glue.etc...The oval gear flow meter material is stainless steel 316L and Aluminium for different applications.Cooperate with DC8S display instrument to get a dosing system(also with digital display and alarm).

FEATURES

• Min flow is 0.5ml/min for oil; 1ml/min for water


• The standard type accuracy is 0.5%


• Stainless steel 316L;Aluminium;PPS material for corrosive medium


• Cooperate with DC8S display instrument to composite a dosing system


• Customized for high pressure(Normal is 32Bar) It's usually used for hydraulic system


• With small size body and easy installation


• The Max flow ratio is 1:800(1~800ml/min for test bench);normal type is 1:200

TECHNICAL

Medium	Suitable for liquid,weak corrosive chemical liquid,eg:water;oil;glue...
Accuracy	Standard type is 0.5%
Pressure	32Bar and customized high pressure
Temperature	-30~80℃,Max temperature is 120℃
Output	Pulse output
Power	4-26VDC power supply
SS Series__
Material	Body:SS316L
	Gear:SS316L
	Bear:SS316L
Medium	Suitable for water and corrosive medium
AL Series__
Material	Body:Aluminium
	Gear:Aluminium
	Bear:SS316L
Medium	Non-corrosive liquid,oil;glue





Model	Flow Range	Connection	K factor
CX-M2	0.5~150 ml/min	G1/8'' Female thread	0.06 ml/p
CX-M3	3-300 ml/min	G1/8'' Female thread	0.14 ml/p
CX-M5	5-1000 ml/min	G1/8'' Female thread	0.36 ml/p
CX-M6	0.5-100 L/h	G1/4'' Female thread	1 ml/p
CX-M9	6-600 L/h	G1/4'' Female thread	5 ml/p
CX-M12	0.3-30 L/min	G1/2'' Female thread	17.5 ml/p
CX-M5.1	1-800 ml/min	G1/8'' Female thread	0.3 ml/p



DIAMETER

MODEL/SIZE	M2  M3  M5	M2  M3  M5(high pressure)	M6	M9	M12
A	30	30	40	47	56
B	62	62	72	79	91
C	G1/8''	G1/8''	G1/4''	G1/4''	G1/2''
D	40	50	50	60	85
E	M5*31	M5*31	M5*40	M5*52	M5*72

RELATED FLOWMETER

1. G Series Micro Flow meter(Positive gear)

The G series coating micro flow meter is positive gear type flow meter,It with more higher resolution,The min pulse factor is 0.015ml/p and for high viscosity medium,,the performance is better than M series micro flow meter.

The G series flow meter is Ball or PEEK bear,It's flow ratio is 1:500....(CLICK IT↓)



1. P Series Micro Flow meter(pps corrosive)

The P series coating oval gear flow meter is suitable for corrosive liquid,the material is PPS(gear,bear,body).Min flow is 1 ml/min; FLOW RANGE:1-100;3-300;5-500;10-1000;50-5000(ml/min)(CLICK IT↓)

APPLICATION&CLIENTS

The oval gear flow meter most used for fuel oil,and hydraulic oil ,hydraulic system .it with widly applications,Beacuse of it can test the min flow for liquid(Min:0.5ml/min),It used for more test and control system.

It more used for Common rail inject test bench;Dispenser;glue;oil;hydraulic oil system for leak;Dosing system(with DC8S) and Customized for high pressure and high temperature...







In this years,Our micro flow meter,Get more positive feedback from market and clients.We have more clients from all over the world,Usually,our clients come to our office in SHANGHAI.We thank for your trust and give us many positice suggestions to improve the performance of micro flow meter...We believe we could provide the better service for you...







INSTALLATIONS

For the furnace oil flow meter,The good performance based on the best installation and technical setting.So plz check the details careful Tks...

1. Plz make sure no dust into the flowmeter before install it;Installa the filter on the upstream and clean the tube...


2. Suggest you install a passby value between the inlet and outlet,Parallel to the flow meter;It can help us to clean the tube.


3. It should be noted to install the draft at horizontally,and for micro flow meter,the best installation is flow from bottom to up.


4. The medium flow direction should same as the sign on the flowmeter body.
