TK-7Y регулятор солнечного нагрева воды под давлением
US $10.00-$30.00
Солнечный водонагреватель коллекторная трубка вакуумная солнечный коллектор солнечная энергетическая система для
- Категория: Solar Water Heaters >>>
- Поставщик: Zhejiang,Kesun,New,Energy,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 264.0 $* | 277.9 $* |
| Aug-15-2025 | 262.47 $* | 275.23 $* |
| Jul-15-2025 | 220.92 $* | 231.48 $* |
| Jun-15-2025 | 258.53 $* | 271.99 $* |
| May-15-2025 | 224.98 $* | 235.58 $* |
| Apr-15-2025 | 253.74 $* | 266.42 $* |
| Mar-15-2025 | 251.83 $* | 264.49 $* |
| Feb-15-2025 | 249.94 $* | 261.94 $* |
| Jan-15-2025 | 246.74 $* | 258.3 $* |
Характеристики
Item Name | Solar collector | ||||||||||||||||
Manifold Casing Material | Aluminium (grade 3A21) | ||||||||||||||||
Frame Material | 6063 Aluminum Alloy（1.8mm） | ||||||||||||||||
Header Pipe Material | 99.93% pure Copper & lead free 45% silver brazing | ||||||||||||||||
Heat pipe Spec | Thickness:0.6mm,14mm condensor | ||||||||||||||||
Fins around heat pipe | Double round aluminum 1.68m | ||||||||||||||||
Insulation | Compressed Glass Wool - K = 0.041W/mK | ||||||||||||||||
Rubber Seals and Rings | HTV grade silicone rubber | ||||||||||||||||
Optimal installation angle | 20-70° Vertical, -5° to +5° Horizontal | ||||||||||||||||
Maximum Operating Pressure | 8 Bar-16psi | ||||||||||||||||
Optimal flow rate | 0.1L/min/tube - 0.026G/min/tube | ||||||||||||||||
Inlet outlet | 3/4" or 1” or 1/2“ optional | ||||||||||||||||
Conversion Factor: h° = 0.70 | |||||||||||||||||
Loss Coefficients: a1 = 1.52, a2 = 0.0085 | |||||||||||||||||
Tube Structure | All-glass double-tube co-axial stricture | ||||||||||||||||
Glass material | High borosilicate 3.3 glass | ||||||||||||||||
Tube size | Φ 58*1800mm | ||||||||||||||||
Outer tube diameter & thickness | Φ 58±0.7mm; Thickness 1.6mm | ||||||||||||||||
Inner tube diameter & thickness | Φ 47±0.7mm; Thickness 1.6mm | ||||||||||||||||
Coating Material: | Cu / SS-AIN (HSS-AIN (L) | ||||||||||||||||
Method sediment: | Tri-element magnetron sputtering coating | ||||||||||||||||
Absorbency: | 0.93 ~ 0.96 (AM1.5) | ||||||||||||||||
Degree of vacuum (Pa) | P ≦ 5.0 × 10 -3 (Pa) | ||||||||||||||||
Glass tube transmittance: | T: ≥0.89 (AM1.5 ISO9806-1: 1994) | ||||||||||||||||
The stagnation parameters: | Y: 240 ℃ ~ 260M / KW | ||||||||||||||||
The average heat loss: | ULT: ≦ 0.60W / (M2▪ ℃) | ||||||||||||||||
Viva la resistance: | 25mm | ||||||||||||||||
Distance from tube to tube(mm) | 75mm | ||||||||||||||||
Pressure-support: | 0.6Mpa | ||||||||||||||||
Material | TU1 copper | ||||||||||||||||
Condenser Size | Φ14mm diameter, 90mm length | ||||||||||||||||
Body Size | Φ8mm diameter | ||||||||||||||||
Heat-transfer-fins | premium complete type | ||||||||||||||||
Max. Working Temp | -37~250℃ | ||||||||||||||||
Start-up Temp | <=30℃ | ||||||||||||||||
Maximum operation pressure | 12 bar (175 psi) | ||||||||||||||||
Daily efficiency | 55% | ||||||||||||||||
Product Details Of Solar Water Heater
1. Is solar water heater a viable alternative to gas or electricity?
Solar should not be seen as a alternative to gas or electricity, but rather a supplement. Solar cannot totally replace the need for gas or electric heating as there are sometimes days when there is little sunlight. When averaged over a year, a correctly sized solar system can provide 60%-70% of a household's hot water needs. Providing more than this is unadvisable, as too much heat will be produced in the summer. The hot water system system can easily be automated so hot water is guaranteed regardless of sunlight levels.
2. Can KESUN solar collectors be used in cold conditions?
Yes.KESUN collectors can be used in temperatures as low as -30℃, although performance is greatly reduced in such extreme conditions. Good heat output is still achieved in mild sub-zero conditions.
3. What happens if one of the solar tubes is broken?
Firstly, tubes are very strong and not easily broken, but if the worst should happen, solar tubes can be replaced very easily. They are inexpensive and available, you can contact us for purchase. The KESUN solar collectors can operate with several broken tubes, but the efficiency will be reduced, so it is recommended that broken tubes be replaced immediately.
4. Will water be heated on a cloudy day?
4. Will water be heated on a cloudy day?
Yes. Although the heat output of the solar collector is reduced on overcast days it will still be able to provide heating. If it is a heavily clouded day or raining, then more gas or electric boosting may be required to maintain water at the required temperature. This system will be automated so you don't have to worry about running out of hot water on a rainy day.
