BSA LT1250/300 Пневматический тормозной башмак сцепления для систем бурения

BSA LT1250/300 Пневматический тормозной башмак сцепления для систем бурения

Категория: Industrial Brake >>>
Поставщик: Henan,Dalin,Rubber,And,Telecommunications,Apparatus,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.24 $*	0.91 $*
Aug-16-2025	0.29 $*	0.0 $*
Jul-16-2025	0.57 $*	0.0 $*
Jun-16-2025	0.44 $*	0.8 $*
May-16-2025	0.77 $*	0.45 $*
Apr-16-2025	0.54 $*	0.62 $*
Mar-16-2025	0.66 $*	0.33 $*
Feb-16-2025	0.22 $*	0.16 $*
Jan-16-2025	0.37 $*	0.20 $*

Характеристики

Product Description

Ventilated Pneumatic Clutch consists of steel ring, coupling fiange, pneumatic air tube, release spring, slipper, friction lining, torsion bar, side panel, air cock fiexed ring.

Industry Applications: Grinding Mills, Marine Propulsion, Metal Forming, Drilling Equipment, Pulp and Paper Machinery.

Ventilated Pneumatic Clutch made in China.It is widely used in China and partly used abroad.

The Ventilated Pneumatic Clutch can be dismantled on the shaft to gain access to its component parts. All parts are available as replacement parts.

Ventilated Construction

1.Pneumatic tire clutch can be divided into radial type and axial type according to the installation position of pneumatic tire and friction plate. Among them, the radial pneumatic tire can be configured into a single exhaust tire and a double exhaust tire.

2.The tire expands when it is filled with Compressed air, and the air pressure is evenly distributed over the Friction Pad Assembly, which is then pushed to hold the drum on the driven shaft. The friction tile assembly is riveted by aluminum backing plate and friction plate, and is guided by a Torque bar fixed on the side plate.

Description of application effect

VC Clutch：
Ventilated pneumatic clutch is a kind of pneumatic clutch with excellent performance developed on the basis of common pneumatic clutch. It has good ventilation and heat dissipation, the pneumatic tire does not bear torque, and it is stable to hang and detach, thus it has higher working performance and service life than the common type.

Detailed Images

The pneumatic tire expands when charged with compressed air, and the air pressure is evenly distributed on the friction shoe assembly, thereby pushing the friction shoe assembly to hug the drum mounted on the driven shaft.

The friction shoe assembly is formed by riveting an aluminum backing plate and friction plates, and is guided by a torque rod fixed on the side plate.
The torque is output from the reducer, transmitted to the active part of the pneumatic tire clutch through the driving hub, and then the pneumatic tire is inflated to push the friction shoe assembly, and the power is transmitted to the driven drum.

Size Information

Model	Rotate speed r/min			Torque N.m			Working pressure Mpa	Pneumatic
Model	Model	Limited	Rated	Limited	Rated	Friction Area	Working pressure Mpa	volumetric
LT500/200	1312-1578	758-912	17110-24970	11406-16646	0.7-1.0	3*2
LT500/250	1586-1701	916-983	23390-26900	15590-17930	0.7-0.8	3*5
LT600/250	1281-1544	740-892	32200-46710	21466-31140	0.7-1.0	4*2
LT700/250	1181-1344	660-793	48200-69910	32100-47300	0.7-1.0	4.2*2
DY700/135	1569-1890	907-1092	24560-35360	16170-23750	0.7-1.0	4
LT800/250	1016-1224	587-707	54240-78660	36160-52440	0.7-1.0	4.66*2
LT900/250	903-1087	522-628	68000-98930	45467-65953	0.7-1.0	3*2
LT1070/200	932-1123	539-668	84600-122670	56400-81790	0.7-1.0	3.0
LT1170/250	765-820	442-474	117740-134130	78490-89420	0.7-0.8	5.7
LT1120/300	----	----	184500-263250	123000-175500	0.7-1.0	3.96*2
LT1250/300	----	----	229500-327000	153000-218000	0.7-1.0	4.4*2
LT965*305	782-957	452-563	99680-142800	78145-96755	0.7-0.9	6.0
LT1168*305	739-890	435-524	108390-147700	88332-99700	0.7-0.9	11

Related Products

Packing&Shipping

The normal package is wooden box(Size: L*W*H). we will according to the clutch size to make the different wooden box,we will make sure the clutch will be safe .

After Sales Service

Pre-Sales and After-Sales Service

Pre-Sales Service：
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service：
* Training how to install the machine, training how to maintain the machine.
* Engineers available to service machinery overseas.

Company Introduction

Henan Dalin Rubber Communication Equipment Co. , Ltd. is a company specializing in the design and manufacture of various pneumatic clutch and accessories processing manufacturers.
Products used in mines, metallurgy, petroleum, steel, chemicals, cement, ships, paper, General Machinery and other high-power mechanical transmission or braking devices.

Our company successively acquired National High and New Technology Enterprise Authentication, National Intellectual Property Management System Certification, passed ISO9001:2008 International Quality System Authentication, OHSAS18001:2007 Occupational Health and Safety Management System Authentication, ISO14001:2004 Environment Management System Authentication, won more than 20 national patents and the provincial award for science and technology advancement. We are level A network supplier of China National Petroleum Corporation, In the meantime, we also have long term cooperation with customers from USA, UK, Russia, etc.
Our company is dedicated to offering our customers with a strict production process and good quality products with scientific and advanced management. We sincerely hope to cooperate with you for our mutual development.

FAQ

1.Price problem: due to the need of product classification, some product prices are the prices of matching combination products.The specific price should be inquired according to actual usage.

2.Experience:Over 20 years of experience in production of rubber products.

3.Requirement: Please inquire about relevant product information according to the product's use and use environment. We will give reasonable suggestions..

4.Quality: We provide reliable product quality, if necessary, we will provide relevant inspection certificates, etc..

5.Question:Please contact us if you have any other questions, we will provide the information you need as much as possible, and hope we can cooperate happily.
