Products Description


Heat dissipation paint H-7020

(1) Product feature
H-7020 is a one-component thermosetting paint.
H-7020 is a one-component thermosetting paint that provides excellent heat dissipation when applied.
It has excellent adhesion to metals, and also has anti-corrosion properties.
With its high heat dissipation properties, it can reduce damage to parts caused by heat and extend product life.
Small trial samples are also available, so please inquire.




(2) Application
Large-scale lighting for stadiums and street lighting, large motors for EVs, high-output module components




(3) Compliant for environment regulation
It can be used to comply with the RoHS Directive, which is required for electronic components.




(4) Product information


As supplied （Typical Value）


Item
Condition
Unit
H-7020
Appearance
visual
ー
White liquid
Specific Gravity
25℃
ー
1.17
Viscosity
25℃
mPa・s
560
Diluent during coating
ー
Xylene


Recommended Dry Condition


Item
Condition
Unit
H-7020
Recommended dry temp.
Hot air oven
℃
160
Recommended dry time
Hot air oven
minute
20
Standard coating thickness
Spray coating
μm
20 ～ 40


As cured


Item
Condition
Unit
Typical Value
Coating film Hardness
pencil hardness 45° 750g
ー
2H
Surface Resistance
25℃
Ω/sq.
above 1013
Breakdown voltage
JIS C2110-1
V
2200 (thickness: 30μm)
3800 (thickness: 60μm)
Adhesiveness
cross cut, cellophane tape peeling (1mｍ)
ー
100/100
Reflection Rate
visible light range
%
90


*Curing conditions : 160℃ - 20minute


This product is made in Japan.
Please contact us for details.
According to some country and regional regulation regarding chemical substances, this product may not be exported.




(5) How to use
Please be sure to stir the product before use, as the contents may settle.
The diluent contains xylene, so please use with caution in case of fire.
Please use a painting booth and pay attention to ventilation.
Wear protective goggles, protective gloves, and a gas mask when painting.
1. Stir the settled material thoroughly.
2. Dilute with xylene to a viscosity that is easy to work with (recommended conditions: 30-40g xylene per 100g paint).
3. Spray paint the substrate (recommended thickness: 20-40 μm).
4. Allow the xylene to dry naturally (recommended dry time: 5-10 minutes).
5. Cure the coating film in a heating and drying oven (recommended curing conditions: 160°C x 20 minutes).
